Rough Country PERF689 - Manual (Page 2)

9278-4” Front Coil Springs
OR
9275-6” Front Coil Springs
1689Box1 OR 1601Box1 (2.8L Engine)
Dr Lower Long Arm& Joint (A)
Pass Lower Long Arm& Joint (B)
Dr Upper Arm (C)
Pass Upper Arm (D)
Cross member Side Plates (E)
Pitman Arm (F)
1/2” Flag Nut-For Frt Crssmbr (2)
1689Box2-For NP231 Transfer Case
Transfer Case Skid Plate (G)
OR
1616Box1-For NP242 Transfer Case
Transfer Case Skid Plate (G)
1689Box3
Long Arm Cross-member (H)
1689Box4
Fr Sway Bar Disconnects (I)
Fr Stainless Steel Brake Lines (J)
U-Bolts (2 3/4” x 6 3/4” or 3” x 8”)
For either axle size
Rear Stainless Steel Brake Line
1079 Adjustable Track Bar Kit
Front Adjustable Track Bar (K)
Track Bar Bracket (L)
Perf2.2Shocks:
Fr RCX 2.2 Series Shocks (M)
RR RCX 2.2 Series Shocks (N)
Lift Options for 4” Kit
Lifted Shackles (1077) (O)
& Add-a-Leaf (6123) (P)
OR
Lifted Springs
Lift Contents for rear of 6” Kit:
Rear Leaf Springs
& Shackles (1077)
Fasteners List:
1689Bag1-In 1689Box1 /1601Box1
For Front Cross member
10mm x 35mm Bolt (6)
10mm Flat Washer (6)
Crush Sleeve (2)
1/2” x 4 1/2” Bolt (2)
1/2” Flat Washer (6)
1/2” Lock nut
For Front Lower Control Arms
9/16’ X 4” Bolt (2)
9/16” Flat Washer (4)
9/16” Lock Nut (2)
For Front Upper Control Arms
10mm x 80mm Bolt (4)
10mm Lock Nut (4)
10mm Flat Washer (8)
For Transfer Case Skid Plate
3/8” x 1” Bolt (2)
3/8” Flat Washer (2)
3/8” Lock Washer (2)
3/8” Self Tapping Bolt (2)
1689Bag2– In 1689Box4
For Fr Sway Bar Disconnect:
4-5/16” x 1” Self Tap Bolts
2-3/8” x 1 1/4” Bolts
2-Thick Washers
2-Disconnect Pins
2-Hitch pins
2-Rod Ends
2-1/2” Nuts
2-1/2” Flat Washer
2-1/2” Flange Lock Nut
2-1/2” Jam Nut
For Rear Brake Line
Brake Line Clip
Brake Line Bracket
KIT CONTENTS
1079 Adj Track Rod:
For Fr Adj Track Rod Part
Bushings
(2)
7/16” ID Sleeve
Heim End
Heim Spacers (2)
7/16” Flat Washer (2)
7/16” Lock Nut
3/4” Jam Nut
For Front Brake Lines
Bracket
(2)
Brake Line Clip (2)
3/8” Crush Washers (4)
1077 Rear Shackles:
For Rear Shackles
(If purchased with 4 1/2” & 6” kit)
Bushings
(4)
Sleeves (2)
9/16” x 4” Bolt (2)
9/16” Lock Nut (2)
14mm x 110mm Bolt (2)
14mm Lock Nut (2)
9/16” Flat Washer (8)
