54. Remove the front brake line from the frame rail hard line as shown in Photo 33 and remove the brake line from the

frame using a T-30 socket. Retain the factory hardware.

55. Remove the brake line from the caliper using a 15mm wrench.
56. Install the new brake line bracket on the frame with the factory hardware using a T30 Torque Bit. Install the brake

line in the bracket and attach to the hard line. See Photo 34. Secure with supplied brake line clip.

57. Install the brake line on the caliper using a 14mm socket and install the caliper on the axle. Tighten using a 13mm

socket.

58. Install the coil springs and reinstall the factory coil spring clips as removed using a 13mm wrench.
59. Install the tires and wheels.
60. Jack up the vehicle and remove the jack stands. Lower the vehicle to the ground.
61. Tighten the upper and lower control arms using a 15mm & 21mm wrench.
62. Proceed to the rear of the vehicle.












PHOTO 33

PHOTO 34

Remove line from the uni-body

Install the new line with bracket
