HDD-M4-1-RM
Video & Audio IP Decoder
969 Horsham Road
l
Horsham, Pennsylvania 19044 USA
l
Phone: 215-675-2053 Fax: 215-675-7543
l
Features
Decode MPEG-2 / MPEG-4 signals from various
sources including DVB-S/S2/T/C, ASI and IP
Enables IP/ASI conversion and IP stream
descrambling
Multi-channel IP unicast and multicast (SPTS
outputs for IPTV)
Program filtering
Pro-MPEG FEC (SMPTE-2022) support
Multiple outputs, including HDMI, HD/SD-SDI,
ASI, YPbPr CVBS, and IP
NTSC, PAL, and SECAM compatible
Optional tuner input for DVB-S / S2 / T / C
Configuration and monitoring through front
panel or SNMP network manager.
BISS I and E support
Applications
IPTV Broadcast Systems
MDU Video Distribution
Digital Signage & Kiosk Displays
EMCORE’s HDD-M4-1-RM is an advanced high-performance MPEG-2 / MPEG-
4 decoder that performs real-time receiving and decoding of HDTV & SDTV
content over DVB and broadband IP networks.
The HDD-M4-1-RM supports input options such as DVB-S/S2, DVB-C, DVB-T,
DVB-ASI and IP allowing it to receive and decode programs from different
content sources. The output options are HDMI, HD-SDI, SDI, DVB-ASI, CVBS,
YPbPr, AES3, stereo analog audio and IP (unicast or multicast) which simplifies
device integration.
The user-friendly HDD-M4-1-RM decoder is an ideal solution for signal
conversion and distribution over IP for the most demanding broadcast or IPTV
applications.
System Design
Enclosed in a ruggedized aluminum housing, the HDD-M4-1-RM is perfectly
suited towards applications that are space contrained and require equipment
with lower power consumption and heat output. The front faceplate has
push-button controls for configuration as well as status LED’s. SNMP network
management support allows remote interfacing for control and system
diagnostics.
SD / HD MPEG 2 or H.264 AVC Video / Audio Decoding
Application Diagram
