TST Series
1 GHZ 2, 4, & 8 Port Multitaps
Specifications Common to All Taps
Bandwidth (MHz)
5-10
10-50
50-300
300-450
450-600
600-750
750-900
900-1000
Isolation Tap-Tap (dB)
18
23
23
23
20
20
19
18
Return Loss (dB)
16
18
20
18
17
16
16
1
Tap Loss (dB±)
1.0
1.0
1.0
1.0
1.5
2.0
2.0
2.5
Power Passing
6 amps AC/DC
Insertion Loss (dB) @ Frequency MHz
2-Way Tap
Nominal
5-10
10-50
50-200
200-450
450-600
600-750
750-860
860-1000
Model
Tap Value
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
TST102-4T
4 dB
TST102-8
8 dB
3.6
3.2
3.4
3.7
4.1
4.4
4.7
4.9
TST102-11
11 dB
2.0
1.7
1.8
2.1
2.4
2.8
3.1
3.2
TST102-14
14 dB
1.6
1.0
1.3
1.4
1.5
1.8
1.9
2.1
TST102-17
17 dB
1.3
1.0
1.0
1.2
1.3
1.7
1.9
2.0
TST102-20
20 dB
0.9
0.5
0.6
0.9
1.0
1.2
1.5
1.6
TST102-23
23 dB
0.9
0.5
0.6
0.8
1.0
1.2
1.4
1.6
TST102-26
26 dB
0.8
0.5
0.6
0.8
1.0
1.2
1.4
1.6
TST102-29
29 dB
0.8
0.5
0.6
0.8
1.0
1.2
1.4
1.6
TST102-32
32 dB
0.8
0.5
0.6
0.8
1.0
1.2
1.4
1.6
4-Way Tap
Nominal
5-10
10-50
50-200
200-450
450-600
600-750
750-860
860-1000
Model
Tap Value
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
TST104-8T
8 dB
TST104-11
11 dB
3.6
3.2
3.4
3.7
4.1
4.4
4.7
4.9
TST104-14
14 dB
2.0
1.7
1.8
2.1
2.4
2.8
3.1
3.2
TST104-17
17 dB
1.4
0.9
1.0
1.4
1.6
1.8
2.0
2.1
TST104-20
20 dB
1.4
0.9
1.0
1.2
1.4
1.7
1.9
2.0
TST104-23
23 dB
0.9
0.6
0.8
1.0
1.0
1.2
1.5
1.6
TST104-26
26 dB
0.9
0.6
0.8
1.0
1.0
1.2
1.4
1.6
TST104-29
29 dB
0.9
0.6
0.8
1.0
1.0
1.2
1.4
1.6
TST104-32
32 dB
0.9
0.6
0.8
1.0
1.0
1.2
1.4
1.6
8-Way Tap
Nominal
5-10
10-50
50-200
200-450
450-600
600-750
750-860
860-1000
Model
Tap Value
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
TST108-11T
11 dB
TST108-14
14 dB
3.6
3.2
3.4
3.7
4.1
4.4
4.7
4.9
TST108-17
17 dB
2.0
1.7
1.8
2.1
2.4
2.8
3.1
3.2
TST108-20
20 dB
1.4
0.9
1.0
1.4
1.6
1.8
2.0
2.1
TST108-23
23 dB
1.4
0.9
1.0
1.2
1.4
1.7
1.9
2.0
TST108-26
26 dB
0.9
0.6
0.8
1.0
1.0
1.2
1.4
1.6
TST108-29
29 dB
0.9
0.6
0.8
1.0
1.0
1.2
1.4
1.6
TST108-32
32 dB
0.9
0.6
0.8
1.0
1.0
1.2
1.4
1.6
TERMINATING TAP
TERMINATING TAP
TERMINATING TAP
Tap Color Coding
4 dB
Green on White
14 dB
Yellow on White
23 dB
Orange on White
32 dB
Red on White
8 dB
Gold on White
17 dB
Purple on White
26 dB
Blue on White
11 dB
Brown on White
20 dB
Black on White
29 dB
Grey on White
