Toner Cable TST Series Mutitaps User Manual
Tst series, 1 ghz 2, 4, & 8 port multitaps
969 Horsham Road
l
Horsham, Pennsylvania 19044 USA
l
Phone: 215-675-2053 Fax: 215-675-7543
l
TST Series
1 GHZ 2, 4, & 8 Port Multitaps
Features
•
Weatherproof self-sealing
F ports helps prevent leak-
age through ports even if
subscriber drop cable is
disconnected.
•
A360 Alloy aluminum
housing with weather
resistant protective powder
coating.
•
Stainless steel hardware
for corrosion resistance.
•
Color coded tap value
labels.
•
Stainless steel FRI gasket.
•
Plastic protective cover
inside.
•
Glass epoxy printed circuit
board with premium com-
ponents for the best elec-
trical performance
•
Neoprene rubber weather
seal gasket for water tight
protection, tested at 15
PSI.
•
Compatible with Scientific
Atlanta
®
SAT series tap
housing.
Continuous RF signal and power pass-thru during tap-plate
removal ensures uninterrupted system services.
RF AC Bypass
