INPUT OPTIONS
The RX8252 Program Transcoder has a single ASI input and a 4
input satellite input module fitted as standard.
Satellite Input Options
The RX8252 satellite input module comes with DVB-S QPSK sup-
port as standard. The unit can optionally be licensed to support
the new highly efficient DVB-S2 satellite transmission standard.
DVB-S2 QPSK License (RX8200/SWO/DVBS2/QPSK)
• Adds DVB-S2 QPSK capability to DVB-S2 input option card
DVB-S2 8PSK License (RX8200/SWO/DVBS2/8PSK)
• Adds DVB-S2 QPSK, 8PSK capability to DVB-S2 input option
card
DVB-S2 16APSK License (RX82XX/SWO/DVBS2/16APSK)*
• Adds DVB-S2 QPSK, 8PSK and 16APSK capability to DVB-S2
input option card
DVB-S2 Low Symbol Rate License
(RX8200/SWO/DVBS2/LSYM)
• Enables DVB-S2 symbol rate of 1 Msym/s to 5 Msym/s
Input Redundancy
The RX8252 Program Transcoder offers as standard automatic
redundancy switching between ASI input and the additional input
option. This redundancy switching capability may be further
enhanced with the following option.
Null Packet Detection Redundancy Switching
(RX8200/SWO/NULL)
• Redundancy switching from primary to secondary input triggered
by presence of null packets in the incoming stream
• User definable percent of null packets to trigger redundancy
switch
TRANSPORT STREAM OUTPUT OPTIONS
The RX8252 Program Transcoder provides ASI transport stream
output as standard. IP transport stream output capability may addi-
tionally be specified.
IP Transport Stream Output (RX8200/HWO/IP/OUT)
• Encapsulation of transport stream output into IP multicast
• MPTS or single SPTS output stream
• 2x Gigabit Ethernet RJ-45 interfaces capability
CONDITIONAL ACCESS OPTIONS
The RX8252 Program Transcoder supports many types of widely
used conditional access systems to allow for secure transmission
of content including Director by Ericsson - the highly secure CA
and flexible receiver control system.
Director by Ericsson (RX8200/SWO/DIR)
• Director CA
• Director over-air control
• Director over-air software downloads
Director by Ericsson Multi-service Decryption
(RX8200/SWO/DIR5/MSD)
• Multi-service decryption for Director by Ericsson
DVB Common Interface (RX8200/SWO/CI)
• Enables support for Conditional Access modules
DVB Common Interface Multi-service Decryption
(RX8200/SWO/MSD)
• Multi-service decryption DVB Common Interface
BISS CA (RX8200/SWO/BISS)
• BISS Mode 1 and BISS Mode E descrambling
BISS Multi-service CA (RX8200/SWO/BISS/MSD)
• Multi-service decryption for BISS
VIDEO TRANSCODING OPTIONS
The RX8252 Program Transcoder offers MPEG-4 to MPEG-2
transcoding. The transcoding offers the capability to transcode up
to 6x 4:2:0 video services and simultaneously monitor one service
on SD composite video and SDI outputs.
Transcode Options
The RX8252 Program Transcoder may be configured with a quan-
tity of SD and/or HD transcodes up to a total of six as required.
HD 4:2:0 transcoding (RX8200/SWO/MP4/TRANS/HD)
• MPEG-4 HD to MPEG-2 HD transcoding
• QTY 1 required per video service
SD 4:2:0 transcoding (RX8200/SWO/MP4/TRANS/SD)
• MPEG-4 SD to MPEG-2 SD transcoding
• QTY 1 required per video service
AUDIO OPTIONS
The RX8252 Program Transcoder provides many different audio
capabilities to allow optimal system interoperability.
Audio Pass-Through Options
The RX8252 Program Transcoder can be enabled to pass-through
to the outgoing transport stream many different types of audio
Dolby® Digital (RX8200/SWO/AC3)
• Enables pass-through of Dolby Digital Audio
• Enables decode and down-mix
• QTY 1 required per Dolby Digital audio service
AAC Audio (RX8200/SWO/AAC)
• Enables pass-through of AAC-LC and HE-AAC audio
• QTY 1 required per AAC audio service
Cable Options
The RX8252 Program Transcoder can be delivered with audio
breakout cables to various types of terminals
XLR Terminal Audio Break-Out Cable
(RX8XXX/CABLE/XLR)
• Provides XLR terminal connections for analogue and digital
audio output
• 1x stereo pair per breakout cable via 2x XLR connectors
Screw Terminal Audio Break-Out Cable
(RX8XXX/CABLE/SCRTRM)
• Provides screw terminal connections for analog and digital audio
output
• 1x stereo pair per breakout cable via 2x Screw terminal connec-
tors
OTHER OPTIONS
The RX8252 Program Transcoder may be configured to offer the
following additional functionality as required
Password Protection of Web Browser (RX8200/SWO/PW)
• Protects Web browser from malicious or accidental changes
*Check availability
