Toner Cable Equipment, Inc.
Specifications Subject To Change Without Notice.
Telephone:
Nationwide:
Fax:
E-mail:
Internet:
TFC TX10-15 F
le
xible F
eeder Ca
ble
215-675-2053
800-523-5947
215-675-7543
http://www.tonercable.com
PHYSICAL SPECIFICATIONS
NOMINAL DIMENSIONS
STANDARD
QUADSHIELD
60
60-40
Braid Coverage%
inches
(mm)
inches
(mm)
Conductor
0.1090
(2.77)
0.1090
(2.77)
Dielectric
0.455
(11.6)
0.455
(11.6)
Sealed APA Tape (1st Outer Conductor)
0.463
(11.6)
0.463
(11.8)
Aluminum Braid (2nd Outer Conductor)
0.490
(12.4)
0.490
(12.4)
Unsealed APA Tape (3rd Outer Conductor)
—
—
0.494
(12.5)
Aluminum Braid (4th Outer Conductor)
—
—
0.523
(13.3)
Jacket
0.590
(15.0)
0.623
(15.8)
Cable Width (Single)
Messenger Diameter (Single)
0.109
(2.77)
0.109
(2.77)
Single Messenger Width
0.814
(20.7)
0.847
(21.5)
Messenger Break Strength
Size
Min
Max
0.109 in (2.77mm)
1800 lb (8007 N)
2190 lb (9742 N)
CABLE WEIGHT [lb./kft. (kg/km)]
Regular
60
60-40
Single
101
(150)
115
(171)
Single Messengered
143
(213)
—
—
Underground
Single Flooded (PVC)
—
—
—
—
Single Flooded (PE)
81
(121)
93
(138)
lifeTime™
Single Flooded
99
(147)
112
(167)
Single Flooded Messengered
—
—
153
(228)
ELECTRICAL SPECIFICATIONS
Nominal DC Resistance @ 68ÞF (20ÞC)
Ohms per kft. (Ohms/km)
Braid Coverage%
Standard
Quadshield
Conductors
60
60-40
Center Conductor
1.35
(4.43)
1.35
(4.43)
Outer Conductor
4.42
(14.50)
2.50
(8.20)
Loop
5.77
(18.93)
3.85
(12.63)
Nominal Capacitance
15.5 pF/ft (50.9 pF/m)
Impedance
75 ± 2 Ohms
Velocity of Propagation
88% nominal
PART NUMBER
BRAID COVERAGE
CONSTRUCTION
STANDARD
QUADSHIELD
Nominal Braid Coverage %
60
60-40
PVC Jacket (Regular)
Single
02850
02852
TX15A60-VB
TX15AQ-VB
Single (Colors)
—
—
Single Messengered
02853
02854
TX15A60-109M
TX15AQ-VB-109M
Polyethylene Jacket (Underground Floodant)
Single Flooded
02851
02858
TX15A60-FEB
TX15AQ-FEB
Single (Colors)
—
02859
TX15AQ-FEC
PVC Jacket (
lifeTime™ Floodant)
Single Flooded
32850
32852
TX15A60-LTVB
TX15AQ-LTVB
Single Flooded Messengered
—
32854
TX15AQ-LTVB-109M
PVC Jacket, Flame Retardant - NEC Article 820 -
“CATV “
Single Flooded
02850V
02852V
TX15A60-VBV
TX15AQ-VBV
Single (Colors)
—
—
PVC Jacket, Flame Retardant - NEC Article 820 -
“CATVR “
Single
02850R
02852R
TX15A60-VBR
TX15AQ-VBR
Single (Colors)
—
—
UL
UL
