Toner Cable TFC TX10-15 Low Loss Drop Feeder User Manual
Tx flexible feeder, Tfc tx10-15 low loss drop feeder, Cable construction
Telephone:
Nationwide:
Fax:
E-mail:
Internet:
3/02
TFC TX10-15 F
le
xible F
eeder Ca
ble
215-675-2053
800-523-5947
215-675-7543
http://www.tonercable.com
969 Horsham Road
Horsham, Pennsylvania 19044 USA
TX Flexible Feeder
®
TFC TX10-15 Low Loss Drop Feeder
Cable Construction
• Copper-Clad Aluminum Inner Conductor
• Foamed PE Dielectric
• Sealed APA Tape 1st Outer Conductor
• Aluminum 60% Braid 2nd Outer Conductor
• Black PVC Flame Retardant Jacket
• Perfect for Multiple Dwelling Units and Any Other Settings Requiring
High Flexibility and Low Attenuation of Signal Strength
Signal Strength of a Hardline Cable
with the Flexibility of a Drop Cable
MAXIMUM ATTENUATION @ 68°F(20 C)
Frequency MHz
dB per 100 feet dB per 100 meters
5
0.21
0.69
55
0.60
1.97
211
1.16
3.81
250
1.26
4.13
270
1.31
4.30
300
1.39
4.56
330
1.45
4.76
350
1.50
4.92
400
1.61
5.28
450
1.71
5.61
500
1.80
5.91
550
1.90
6.23
600
1.98
6.50
750
2.23
7.32
870
2.41
7.91
1000
2.59
8.50
Attenuation increases with increasing temperatures and decreases
with decreasing temperature at the rate of 0.1%/
o
F (0.18%/
o
C)
