Parameter Value
System
Standards: MPEG-2/DVB Compatible
EN 300 421, EN 300 468
Demodulation: DVB-S QPSK, DVB-S2 QPSK and 8PSK
Tuner
Number of RF Inputs: 4 (1 active at a time)
Input Level: -25 dBm to -65 dBm per carrier
Frequency Range: 950 MHz to 2150 MHz
Symbol Rate Range: DVB-S: 1.0 to 45 MSymbols/s
DVB-S2: 10.0 to 30 MSymbols/s
1.0 to 10 MSymbols/s
Carrier Capture Range: ≥ ±3.0 MHz (1-10 MSymbols)
≥ ±5.0 MHz (10-30 MSymbols)
Satellites: C-band and Ku-band
Input Impedance: 75 Ω
Analog HD Video Output
Number of Channels: 1
Video Decompression Type: MPEG-2 4:2:0 and MPEG-4 AVC 4:2:0
Video Standard 1080i @29.97, 1080i @ 25,
720p @ 59.94, 720p @ 50
Horizontal Video Resolutions: 1080i: 1920, 1440, 1280
720p: 1280, 960, 640
Analog SD Video Output
Number of Channels: 1
Video Decompression Type: MPEG-2 4:2:0and MPEG-4 AVC 4:2:0
Video Standard: NTSC and PAL B/G/I/D/M/N
Maximum Video Resolution: 720x480/576 digital audio/video output
(future)
Analog Audio Output
Number of Channels:
2 stereo pairs / or 4 mono channels,
5.1 channel down-mix
Audio Decompression: MPEG or Dolby ® Digital (AC-3). HE-AAC
single stereo pair or Dolby ® Digital Plus
single stereo pair available in anticipated software
release.
Output Level: Balanced, adjustable audio outputs are
factory set for unity gain (0 dBm out over
600 ohms for 0 dBm in). Output is
adjustable at the front panel by ±6.0 dB
(ref., 100 kilohms) Factory calibrated to
+18 dBu (at full scale).
Frequency Response: ±0.5 dB, 20 Hz, to 20 kHz
(ref. 100 kilohms)
Total Harmonic Distortion: <0.3% at 1 kHz (ref. 100 kilohms)
Dynamic Range 85 dB (CCIR/ARM weighting)
Crosstalk 80 dB at 1 kHz (typical)
Digital Outputs (optional)
Digital HD Video Output
Number of Channels: 1
User Selectable Output Ports: 2
Output Type:
BNC
Output Format: HD-SDI, SMPTE-292M
SDI, SMPTE-259M
Embedded Audio: 2 audio programs, PCM or pass-through
2 digital audio outputs (1 stereo ch. each)
BNC, AES-3id, SMPTE 276M
Aspect Ratio
Display Aspect Ratios: 4:3, 16:9
Aspect Ratio Conversions 4:3 : 16:9 Letterbox, 14:9 Letterbox,
Center Cutout
for Down-Conversion: 16:9 : Center Cutout
Aspect Ratio Conversions 4:3 : 16:9 Letterbox, 14:9 Letterbox,
Center Cutout, None
for SD Programs: 16:9 : Scale to 16:9
Parameter Value
VBI
NTSC: Lines 10 to 22 fields 1 and 2
Line 21 closed captions
NABTS, AMOL I and II (Neilsen), VITC,
WSS
PAL: Lines 7 to 22 fields 1 and 2
WST, WSS, VPS, VITC
Data Outputs
RS-232 Asynchronous Data
Rates: 300, 1200, 2400, 4800, 9600, 19,200,
38,400 b/s
Ethernet Output for IP Data
Connector: RJ-45, 10/100BaseT
Rates: Up to 10 Mbps
Conditional Access
PowerVu CA: DES or DVB
DVB Descrambling: BISS Mode 1/E
DVB-CI
Interface: 2 CI Slots - EN 50221
CA Method: Multicrypt, Simulcrypt
CAS: Irdeto, Viaccess, Nagravision, Conax
MediaGuard, Cryptoworks available in an
anticipated future software release
Other Outputs
MPEG-2 Transport Input:
EN50083-9, DVB-ASI coaxial,
188/204 byte packets
MPEGoIP
Physical: RJ-45
Ethernet: 10/100/1000BaseT
Output Modes: UDP Raw, RTP
Ethernet Output for RJ-45, 10/100/1000BasteT
Control and Monitoring:
MPEG-2 Transport Output: EN 50083-9, DVB-ASI coaxial,
188 byte packets
Programmable Relay Output: Alarm or configurable to one of the 8
open collector outputs
Cue Tone Output
Balanced Audio Output: -3.0 dBu ±3 dB, 600 ohms
Output Impedance: <50 ohms
Cue Trigger Outputs
Number of Outputs: 8
Type: Open Collector
Environmental Specifications
Operating Temperature: 0°C - 50°C (32°F - 122°F)
Storage: -20°C - 70°C (-4F° - 158°F)
Chassis Mechanical Specifications
Dimensions (WxDxH): 17.35 x 13.78 x 1.72”
44.07 x 35.0 x 4.37 cm
Weight: 10 lbs (4.5 kg) approx.
Power
Voltage Range: 100 V to 240 VAC
Line Frequency: 50/60 Hz
Power Consumption: 37 W max.
LNB Power on Satellite Input: +13 V/+18V @400 mA max.
D9854
Advanced Program Receiver
SPECIFICATIONS
