DIRECTV Receiver Front Panel
Getting Started
DIRECTV Receiver Front Panel
Your equipment may not look exactly like the model illustrated.
1)
POWER – Turns your DIRECTV Receiver on or off. Your DIRECTV Receiver still tunes and
receives messages when powered off.
2)
REMOTE SENSOR – The infrared sensor picks up commands from the remote control.
3
) GUIDE – Displays the onscreen program guide.
4)
MENU – Brings up the Quick Menu to access settings and services.
5)
ARROWS – Move the onscreen highlight up, down, left or right.
6)
SELECT – Selects the item highlighted.
7)
ACTIVE –
Displays the DIRECTV Interactive Home Page—local weather and more!
8)
INFO – Displays channel banner or info to a highlighted program or channel cell.
9)
DOOR PANEL – The access card slot and RESET button are located behind the door panel.
1 2
3
4 5 6
7
8
9
5
