Toner Cable FAM Attenuator Pads User Manual
Attenuator pads, 1 ghz fam series / 2.5 ghz sfam series, Fam 1 ghz attenuators
969 Horsham Road
l
Horsham, Pennsylvania 19044 USA
l
Phone: 215-675-2053 Fax: 215-675-7543
l
Attenuator Pads
1 GHz FAM Series / 2.5 GHz SFAM Series
FEATURES
Tin/Nickel Plated Solid Brass
100 dB RFI Minimum
Female to Male Fittings
22 Gauge Steel Center Pin
9 Different Values
FREQUENCY RANGE:
5-1000 MHz
IMPEDANCE:
75 ohms IN and OUT
ACCURACY:
6% or ± .5 dB
(whichever is less)
SPECIFICATIONS
FAM 1 GHZ Attenuators
MODEL
FAM-1
FAM-2
FAM-3
FAM-6
FAM-8
FAM-10 FAM-12 FAM-16 FAM-20
ATTENUATION (dB)
5-600 MHz
0.9
2.2
2.7
5.6
7.5
9.6
11.5
15.8
19.4
600-750 MHz
1.0
2.1
3.4
6.3
8.2
10.6
12.5
16.5
19.8
750-900 MHz
1.1
2.2
3.4
6.3
7.8
10.6
12.5
16.5
19.3
900-1000 MHz
1.1
2.3
2.5
5.5
7.4
10.3
11.7
15.7
18.8
RETURN LOSS
(dB) minimum
5-600 MHz
24
23
23
26
26
22
22
26
20
600-750 MHz
22
21
21
24
22
21
21
22
19
750-900 MHz
18
18
20
22
20
20
20
20
18
900-1000 MHz
18
18
18
18
18
18
18
18
17
