HIGH-DENSITY OLT CHASSIS:
1 Platform Management Module (PMM) Slot
2 Platform Switch Module (PSM) Slots
18 Platform Interface Module (PIM) Slots
SUBSCRIBER-SIDE INTERFACES:
IEEE 802.3 EPON
18 PIMs per chassis x 4 PONs per PIM = 72 PONs
72 PONs with 1 x 32 split = 2,304 EPON ONTs per OLT
ITU G.984 GPON
8 PIMs per OLT x 8 PONs per PIM = 64 PONs
64 PONs with 1 x 32 split = 2,048 GPON ONTs per OLT
IEEE 802.3 Point-to-Point
8 PIMs per OLT x 40 GigE ports = 320 P-to-P ports
320 Point-to-Point ONTs per OLT
NETWORK-SIDE INTERFACES:
10 x IEEE 802.3z Gigabit Ethernet via SFP (PSM-01)
6 x IEEE 802.3ae 10 Gigabit Ethernet via XFP and 4 x IEEE
802.3z Gigabit Ethernet via SFP (PSM-02)
MANAGEMENT:
T7 Element Management Suite
Flow-Through Provisioning
Strong QoS & SLA Enforcement Tools
GUI & Cisco-based CLI
SNMP
POWER REQUIREMENTS:
Dual Inputs, -40.5 VDC to -60 VDC
560 W nominal, 700 W maximum for the T7 OLT
75 W nominal, 85 W maximum for the T7 COLT
ENVIRONMENTAL OPERATING TEMPERATURE:
0° C to +50° C for the T7 OLT
-40° C to +60° C for the T7 COLT
HUMIDITY:
10% to 90% relative humidity, non-condensing
SAFETY:
ANSI / UL60950-2000 with UL50
FCC FDA CFR21, Part 1040
IEC 60950
USDA RURAL DEVELOPMENT LISTED
PHYSICAL DIMENSIONS:
T7 OLT
17.5” W x 24.5” H x 12” D
44.45cm W x 62.23cm H x 30.48cm D
T7 COLT
17.5” W x 3.5” H x 12” D
44.45 cm x 8.89 cm x 30.48 cm
WEIGHT:
T7 OLT (fully populated)
88 lbs.
39.92 kg
T7 COLT (fully populated)
22 lbs.
9.98 kg
NEBS:
NEBS Level 1
NEBS Level 3 (pending)
EMI/EMC:
FCC CFR47, Part 15
EN 55024: 1998
EN 55022: 1998
RELIABILITY:
MTBF redundant configuration availability:
> 0.99999 at 40°C, ground fixed in accordance with
Telecordia TR-332
SERVICE:
Modular design for ease of maintenance and upgrades
All modules are hot-swappable
MOUNTING OPTIONS:
Standard relay rack (19” or 23”)
Trident7 ®
2SWLFDO/LQH7HUPLQDOV
