Specifications
HDME Series
HD Encoder / QAM Modulator
INPUT
Input Connectors HDMI input (Video+Audio) HDMI input (Video+Audio) x2
Y, Pr, Pb Component input (Video) Y, Pr, Pb Component input (Video) x2
Composite input (Video) Composite input (Video) x2
L / R Channel Audio input (Audio) L / R Channel Audio input (Audio) x2
Coaxial SPDIF input (Digital Audio, AC3 Pass
Through or LPCM) Coaxial SPDIF input (Digital Audio, AC3 Pass
Through or LPCM) x2
Optical SPDIF input (Digital Audio, AC3 Pass
Through or LPCM) Optical SPDIF input (Digital Audio, AC3 Pass
Through or LPCM) x2
Video Input Level 0.7 – 1.4V(peak‐to peak) 0.7 – 1.4V(peak‐to peak)
Video Mode 480i,480p,576i,576p,720P50,720P60,
1080i50,1080i60
480i,480p,576i,576p,720P50,720P60,
1080i50,1080i60
Audio input Stereo / Digital Stereo / Digital
Audio Input Level 0.4 – 0.8V (p‐to‐p) 0.4 – 0.8V (p‐to‐p)
Input Impedance 75Ω 75Ω
OUTPUT
Frequency Range 54‐864MHz (2‐135) 54‐864MHz (2‐135)
Output Level 40 dBmV 40 dBmV
Output Impedance 75 ohm 75 ohm
Channel Bandwidth 6 MHz 6 MHz
Channel Level
Adjustment
20 dB typ. 20 dB typ.
MER 37 dB min. 37 dB min.
MODULATION
Video Resolution 1080i /720p/576i/576p/480p/480i
1080p @MPEG‐AVC 1080i /720p/576i/576p/480p/480i
1080p @MPEG‐AVC
Video Compression AVC MP@Level4 / MPEG2 MP@HL AVC MP@Level4 / MPEG2 MP@HL
Audio Compression MPEG1 Layer II/ AAC (Advanced Audio Codec)
AC‐3 Pass through MPEG1 Layer II/ AAC (Advanced Audio Codec)
AC‐3 Pass through
Constellations 64 QAM / 256 QAM 64 QAM / 256 QAM
Control/Monitoring
Front Panel LCD Control Yes Yes
Remote Setup Functions Yes Yes
Remote Monitoring /
Status Yes Yes
GENERAL
Power Supply 12 VDC 3 Amp 12 VDC 3 Amp
Consumption 1300 mA 1700 mA
Languages English English
Dimensions 482.7mm x 240mm x 44.4mm
(19" x 9.45" x 1.75") 1RU 482.7mm x 240mm x 44.4mm
(19" x 9.45" x 1.75") 1RU
Weight 6.85 lbs 7.05 lbs
HDME101 HDME201
Available in Annex A or Annex B
