HDME Series
HD Encoder / QAM Modulator
969 Horsham Road l Horsham, Pennsylvania 19044 USA l Phone: 215-675-2053 Fax: 215-675-7543 l [email protected]
The HDME is a perfect solution for Small Cable
Systems, Hotels, Motels, Sports Bars, Casinos,
Restaurants, Gyms, Schools, Industrial or
Commercial Applications and anywhere an A/V -
Digital source needs to be added to a TV system.
The Thor Digital HDME series of HD digital modula-
tors are designed to take an HD component signal
and digitally encode it, and then modulate it on a
QAM channel for distribution to a digital TV. There
are 2 models available, HDME-101 encodes a single
program and outputs it to QAM, the HDME-201
encodes two separate programs (2 different sources)
and output them on a single QAM. This modulator
available in Annex A or Annex B.
Features:
• One or Two Program Encoder / QAM
Modulator
• Multiplex All the Programs on One QAM
• Frequency Agile QAM Channel, from
Channel 2 to Channel 135
• 40 dBmV RF Output Level
• Virtual Channel Numbering
• Short Program Name (7 Digits)
• 38 dBmV MER
• Rack Mount or Desktop
• GUI for Management and Control
(Third Quarter Release)
• Compression Codec MPEG2 or H.264
Single and Dual Program Encoders
with Internal Multiplexer / QAM Modulator
