Min Typ Max Units Notes
Input Signal Composite or S-Video 1
Output Signals Composite and S-Video 1
I/O Impedance 75 Ohm
Input Level 0.6 1.0 1.4 V
Output Level 1.0 V 2
Bandwidth 6 MHz
SNR (NTC7 Lum-Weighted) 67 72.5 dB
SNR (Unified Lum-Weighted) 67 73.0 dB
Differential Gain 1.3 %
Differential Phase 0.7 °
Line Time Distortion 0 0.25 0.50 %
Chrom-Lum Delay -20 0 20 ns
Chrom-Lum Gain 98 100 103 %
Conversion 10-bit 4:2:2 per ITU-R BT.601
Specifications
OTDV-1250
Multimedia/Multiformat Transport Link
NOTES:
1) The transmitter accepts either NTSC or PAL composite or S-Video input. If both are present, the S-Video signal will be used. The
receiver always presents both composite and S-Video outputs.
2) The output level will track the input level.
3) The standard transceiver model offers two audio channels. A special unidirectional model offers four(4) audio channels.
4) Input impedance is switch selectable by the user.
5) The data protocol is switch selectable by the user.
6) The OTDV-1250 utilizes high-efficiency switching power supplies internally. The power dissipation is nearly constant as the input voltage
changes. The highest current draw will occur at the lowest input voltage and vice versa. Note that excessive noise and ripple on the
power supply may degrade some of the performance parameters.
7) All test results are at +25°C with a +12V to +15V power supply.
Video Specifications
Min Typ Max Units Notes
Number of Channels 2 4 3
Frequency Response 20 20,000 Hz
THD+N -85 -78 dB
Input Impedance 600 10,000 Ω 4
Input Level 10 dBu
Gain -1 0 dB
Resolution 24 bits
Audio Specifications
Min Typ Max Units Notes
Number of Channels 1
Protocol RS-232 or RS-422 5
Data Rate (RS-232) 155 kb/s
Data Rate (RS-422) 1 Mb/s
Data Specifications
Min Typ Max Units Notes
Number of Channels 1
Auto Negotiating 10Mb/s or 100 Mb/s
Ethernet Specifications
Min Typ Max Units Notes
DC Input Voltage 10 20 V
DC
6
DC Current 0.30 0.53 A 6
Power 6 W 6
Electrical Characteristics
Min Typ Max Units
Module Weight 25.4 oz
720 g
Module Dimensions 11.0 x 6.0 x 1.25 in
279x152x32 mm
Physical Characteristics
Min Typ Max Units
Operating Temp. Range 0 +50 °C
Storage Temp. Range -10 +60 °C
Humidity 5 90 %
Environmental Characteristics
