OTDV-1250
Multimedia/Multiformat Transport Link
969 Horsham Road l Horsham, Pennsylvania 19044 USA l Phone: 215-675-2053 Fax: 215-675-7543 l [email protected]
The Olson OTDV-1250 Video/Stereo Audio, Data and Ethernet Fiber Optic Link pro-
vides a very high-quality system for transporting baseband NTSC or PAL video sig-
nals, stereo audio signals and bidirectional data with complete EMI immunity via multi-
mode or single-mode optical fiber. The combination of video, stereo quality audio, data
for touch screens, pan, tilt & zoom or pure data transport for communications and the
addition of autonegotiating 10/100Mb/s Ethernet make these links ideal for broadcast,
contribution and distribution quality V/A/A transport, teleconferencing, distance learn-
ing, and surveillance applications. Each unit is built in a rugged, shielded enclosure.
Units are available with four channels of audio and unidirectional transport options.
The defining feature of the OTDV-1250 is versatility. While there are numerous fiber
optic broadcast transport links available, the addition of user/field-swappable SFP
modules allows the unit to be rapidly reconfigured for any conceivable fiber require-
ment.
All signals are handled using state-of-the-art digital techniques resulting in no degra-
dation in performance regardless of the fiber type and distance. All signals are digi-
tized to a single serial data stream that easily fits into Gb/s data stream. Extensive use
of overhead messaging allows the two units to be aware of problems at the far end.
The world’s most versatile and high-
est quality unidirectional or bidirec-
tional baseband NTSC or PAL B, D,
G, H or I video & audio transport link
includes selectable low-speed data
(RS-232 or RS-422) and auto-negoti-
ating 10/100Mb/s Ethernet.
• Field interchangeable SFP standard
interface allows the unit to instantly be
adapted to transport over multimode
fiber, single-mode fiber at 1310nm,
1550nm, CWDM, DWDM, or even bidi-
rectionally on a single fiber
• Composite and S-Video NTSC or PAL
video inputs and outputs! The receiver
always presents both formats, so format
conversion can be done on the fly. For
instance, composite video can be put in
the transmit end and S-Video can be
used at the receive end
• 12-Bit Digitized Video yields Broadcast
quality video
• 24-bit Stereo audio offers unexcelled
performance
• Multiple LED indicators and alarms for
easy setup and maintenance
• Unit accepts any DC power supply volt-
age from +10V
DC
to +20V
DC
Ordering Information
OTDV-1250-B NTSC Only - Bidirectional Digital Video, Audio, Data Transport Link.
OTDV-1250-TA NTSC Only - Transmit Only Digital Video, Dual Audio, Data Transport Link.
OTDV-1250-RA NTSC Only - Receive Only Digital Video, Dual Audio, Data Transport Link.
OTDV-1250-TAA NTSC Only - Transmit Only Digital Video, Quad Audio, Data Transport Link.
OTDV-1250-RAA NTSC Only - Receive Only Digital Video, Quad Audio, Data Transport Link.
OTDV-1250P-B PAL B, D, G, H and I Only - Bidirectional Digital Video, Audio, Data Transport Link.
OTDV-1250P-TA PAL B, D, G, H and I Only - Transmit Only Digital Video, Dual Audio, Data Transport Link.
OTDV-1250P-RA PAL B, D, G, H and I Only - Receive Only Digital Video, Dual Audio, Data Transport Link.
OTDV-1250P-TAA PAL B, D, G, H and I Only - Transmit Only Digital Video, Quad Audio, Data Transport Link.
OTDV-1250P-RAA PAL B, D, G, H and I Only - Receive Only Digital Video, Quad Audio, Data Transport Link.
Order SFP Modules Separately, contact Toner Cable for Model / Configuration Options
