QMOD-SDI 1.5 HD-SDI Modulator
Applications
3G, HD-/SD-SDI
HD/SD Cable Receivers
HD/SD Satellite Receivers
HD/SD Media Sources
Sources
•
One HD-SDI input, 3G 1080p and 1080i/720p 59.94/60 Hz HD-SDI, and
SD-SDI 480i widescreen/4:3 video; also accepts embedded 608/708
captioning and AC-3/AES audio
•
One Component input, 1080i, 720p, 480p, 480i video
•
One Composite video input for encoding, captioning, or EAS use
•
Stereo, optical and coax audio inputs
Encoding
•
Creates a high-definition 720p/1080i MPEG-2 stream for broadcast
•
Accepts stereo, PCM, or pass-through AC-3 audio, can create two MTS
sub-channels for each input, supporting two languages each
•
Includes captioning from Line 21 data on composite video inputs
•
Flex encoding downscales 1080p to 1080i, allows use of 720p/1080p 60Hz
sources, and compensates for 60/30 Hz sources such as consumer HD
cameras
•
QMOD Scaling upgrade allows full video up- and down-conversion
•
QMOD 2-channel upgrade allows selection of inputs to create
2 HD channels
Output
•
Delivers a fully agile QAM 64/256 digital cable channel 2-135
•
Up to 270 HD Programs/Channels per system
•
Streams IPTV from GigE Ethernet port
•
Distributes channel over an on-site broadband cable system with
adjustable output level to 29 dBmV, compatible with all cable format
broadband systems
Operation
•
Sets up with front-panel buttons and easy to use menus, including inputs,
encoding, channel, and RF options.
•
Onboard Web page for setup and monitoring
•
Control with IP Telnet commands
•
Saves power and rack space using efficient design
•
Includes compact switching power supply
•
Mounts in optional 1RU single (RK1) or dual (RK2EZ) 19” rack kits
•
Meets RoHS safety and California energy standards
Employing a totally new HD encoding
technology, the QMOD-SDI1.5 continues
the QMOD
TM
track record for quality and
innovation, setting a new benchmark for
features and performance. In addition to
standard SDI resolutions, the QMOD-SDI
can accept 3G SDI and 60/30 Hz feeds
from prosumer SDI sources. Users can
upgrade operation for full scaling and dual-
channel operation by entering optional
upgrade key codes.
