Toner Cable RMM12 Minirack Headend System Chassis User Manual
Minirack headend system
Specifications Subject To Change Without Notice
Rev 12-11
©Toner Cable Equipment, Inc.
969 Horsham Road
l
Horsham, Pennsylvania 19044 USA
l
Phone: 215-675-2053 Fax: 215-675-7543
l
Minirack Headend System
RMM12 MINIRACK HEADEND SYSTEM CHASSIS SPECIFICATIONS
MECHANICAL
Dimensions:
3.5'' H x 19'' W x 9.4''D
(89 mm H x 482 mm W x 239 mm D).
Weight:
2.4 lbs (1.1 kg)
RMM4 MINIRACK HEADEND SYSTEM CHASSIS SPECIFICATIONS
MECHANICAL
Dimensions:
1.75'' H x 19'' W x 8.5''D
(44 mm H x 482 mm W x 216 mm D).
Weight:
2.8 lbs (1.3 kg)
PSM121 MINIRACK POWER SUPPLY SPECIFICATIONS
GENERAL
Power Requirements:
100-240 VAC (and ±10% of end limits)
Frequency:
50-60 Hz
AC Input Power:
75 Watts
Operating Temperature Range:
0° to 50° Celsius (32° to 122° Farenheit), ambient
Output Voltages:
+5 VDC @ 4.75 Amps maximum
+12 VDC @ 3.0 Amps maximum
MECHANICAL
Dimensions:
3.5'' H x 4.2'W x 9.4'' D
(89 mm H x 107 mm W x 239 mm D).
Weight:
2.6 lbs (1.2 kg)
CONNECTORS
AC Input:
IEC Type
DC Output:
37 pin “D” type
Fuse (Internal, AC Input):
Internal fuse on AC input; 2A, 250V, SLO-BLO, 5-20 mm
Power supply assembly employs short circuit
and over-voltage protection.
