MUX-12A-IP
12:1 ASI-to-IP Multiplexer 12x ASI ◄► 1x GbE
Specifications
1000Base-T Ethernet (GbE)
Connector: 1 x RJ45
Format: Gigabit Ethernet (GbE)
Data Throughput: 214 Mbps
Standard: IEEE 802.3 10/100/1000Base-T Ethernet
UDP/RTP: Supported and user-selectable
Address Assignment: Single IPv4 address & port; user-selectable
ASI
Connector: 2 x BNC
Format: DVB-ASI
Data Throughput: 214 Mbps
Standard: ETSI EN 50083-9
Indicators:
Front Panel: Power (1x Green LED)
ASI Input Status (12x Green LEDs)
Rear Panel: Status (1x Green LEDs)
Remote Monitoring/Control: GUI-based menu via Web browser
Front-panel RJ45 interface
(10/100 Base-TX Ethernet)
SNMP v2: Temperature
ASI Status
Error Log
OUTPUT
ALARMS / MONITORING / CONTROL
Dimensions (W x D x H) : 19.0 x 16.875 x 1.625 inches (483 x 429 x 41 mm)
Power: 115 to 230 VAC/50 to 60 Hz
(Fuse: 2.0 amp, 250 VDC, SloBlo)
Power Dissipation: 17 W
Weight: 7 lbs (3.2 kg)
Operating Temperature: 32 to 122 °F (0 to 50 °C)
Storage Temperature: -13 to 158 °F (-25 to 70 °C)
Operating Humidity: 0 to 95% RH @ 35 °C max, non-condensing
Storage Humidity: 0 to 95% RH @ 35 °C max, non-condensing
GENERAL
Connectors 12 x BNC
Format: DVB-ASI, 270 Mbps
Standard: ETSI EN 50083-9
INPUT
No. of programs per input ASI: 12 Unencrypted Multi-program Transport Stream
(MPTS)
No. of programs in GbE output: 20 MPTS max
No. of PID per program: 10 per SPTS including PAT, PMT, PSIP
Packet ID (PID) management: User-defined editing/re-mapping is allowed
PAT (Program Association Table): Supported
PMT (Program Map Table): Supported
VCT (Virtual Channel Table): Supported
MGT (Management Table): Supported
Audio standards: Dolby® AC3, MPEG-1 layer 2, AAC
Audio Services per program: 3 max
MULTIPLEXING PROFILE
