Toner Cable DNP100 Network Media Player User Manual
Dnp 100, Network media player

DNP100
Network Media Player
969 Horsham Road
l
Horsham, Pennsylvania 19044 USA
l
Phone: 215-675-2053 Fax: 215-675-7543
l
The Drake DNP100 is a multi-output network media player
capable of playing multi-layered MPEG-2 or MPEG-4 streams
including an optional webkit/web browser-generated overlay.
Once loaded with user-selected content, the DNP100 will output
video stream resolutions of 480p, 720p, or 1080i through multiple
synchronized outputs including Component, HDMI, Composite,
and VGA output ports. These output ports then deliver the
enhanced bit rate SD or HD content to the Drake DSE24 HD
Digital Signage Encoder, the SDE24 or HDE24 MPEG Encoder
Solution for QAM Modulation.
Features
• Enhanced bit rate for 1080i output
• Linux-based Operating System
• Network controlled API
• Webkit QT web browser for multi-layering
overlays
• RS-232 output for commercial controlled
environments
• API for native applications
• Synchronous triple output video
• LCD system status display
Products for Use
with DNP1000
