OT-DCM-F
Dispersion Compensation Module
969 Horsham Road l Horsham, Pennsylvania 19044 USA l Phone: 215-675-2053 Fax: 215-675-7543 l [email protected]
The OT-DCM-F Series Fiber-Based Dispersion Compensation
Module removes distortion from optical signals that have traveled
long distances over standard, positive dispersion, SMF-28 fiber. In
digital systems, this dispersion limits the maximum transmission
distance at a given data rate and causes increased BER. In analog
systems, this dispersion manifests itself as second order distortion
in the signal. The OT-DCM-F Dispersion Compensation Module
cancels out the fiber’s positive dispersion, increasing transmission
distance and enhancing the fidelity of all types of optical signals.
Applications
• Increase Distance and Decrease
BER of Digital Fiber Optic Links
• Reduce Distortion in Analog Fiber
Optic Links
• Cancel Out Dispersion Caused by
Standard SMF-28 Fiber
Features
• Can be Selected for a Wide Range
of Distances
• Wide Optical Bandwidth
• No Need for Precisely Tuned
Channel Wavelengths
• Works with Both Analog and Digital
Signal Formats
Operating Specifications
Operating Wavelength C-Band: 1525-1565 nm
Operating Temperature -35 to +70 °C
Storage Temperature -40 to +75 °C
Relative Humidity 1 <90 %
Connector Return Loss dB <-55 dB
Module Return Loss <-55 dB
Optical Connector SC/APC or FC/APC
Pacakage Dimensions 19" W x 1.72" H x 11.81" D in
482.5 W x 43.6 H x 300 D mm
Notes: 1) Non-condensing environment only
