• 4xCOFDM inputs

• F connector
• 49 - 861 MHz frequency range

(center frequency)

• 7 and 8 MHz channel bandwidth

(6 MHz optional)

• -20 to -65 dBm input level
• 1/4, 1/8, 1/16, 1/32 guard interval
• 1/2, 2/3, 3/4, 5/6, 7/8 FEC
• FEC: Reed Solomon & Viterb fully compliant with

ETS 300 744 and NorDig 2 specifications

• Non-inverted and inverted spectrum
• 2k and 8k carrier mode
• QPSK, 16QAM, 64QAM modulation
• Supports reception of MPTS and SPTS
• Service filtering
• ASI monitoring port
• 10/100/1000BaseT manageport (RJ45)
• Enables WEB management
• 2 slots wide

• 4xQAM inputs

• F connector
• 51-858 MHz frequency range
• 7 and 8 MHz channel bandwidth

(6 MHz optional)

• 4, 16, 32, 64, 128, 256 QAM mode
• 0.87-6.9 Ms/s
• Non-inverted and inverted spectrum

• FEC: ITU-T J83 annex A, B, and C, and ETS

300 429

• Supports reception of MPTS and SPTS
• Service filtering
• ASI monitoring port
• 10/100/1000BaseT manage port (RJ45)
• Enables WEB management
• 2 slots wide

• 4x8VSB Inputs

• F connectors
• 50 to 860 MHz Frequency Range
• -34 to +40 dBmV input level
• Broadcast band
• Supports reception of MPTS and SPTS

• ASI monitoring port
• Service Filtering
• 10/100/1000 BaseT management port (RJ45)
• Enables WEB management
• 2 slots wide

DVB-C Input w/Management (EN 300 429)

*MC/4QAM-MMI

8VSB Input w/Management

*MC/4 x8VSB-MMI

DVB-T Input (EN 300 744)

*MC/4COFDM-MMI

• 10/100/1000BaseT input card (RJ45)

• Mini-GBIC interface (SFP) for optical input
• Supports UDP/RTP Multicast/Unicast

transmission

• Supports multiple of output cards
• Streaming of up to 850 Mbit/s
• Maximum 250 service per output card

• Transport stream, MPEG-2 SD/HD and MPEG-4

SD/HD video formats

• Supports streaming of SPTS
• Support streaming of MPTS with Multiplexing

(optional)

• PSI/SI regeneration
• PCR regeneration
• 1 slot wide

Ethernet Output

*MC/GBIPOUT

OUTPUT MODULES

• 4xASI outputs

• BNC connectors
• 213 Mbit/s per output
• 4 different multiplexed outputs
• Maximum 250 service per output card (sum of all

4 ports)

• Transport stream output, SPTS and MPTS
• Output format constant bit-rate
• PSI/SI regeneration
• 1 slot wide

ASI Output

*MC/4ASIOUTMX

• 8 QAM outputs, 4 and 4 paired

• Full digital modulation and upconversion
• DOCSIS 3.0 RF compliant
• 32 / 64 / 128 / 256 QAM modulation
• Frequency range of 50 – 850 MHz
• Frequency step size of 12.5 kHz
• Frequency stability of 5 ppm
• Output level with 8 carriers on of 40 to 50

dBmV per carrier

• Output level adjustment step size (GUI) of 0.5 dB

• 4.48 to 7.00 Mbaud symbol rate
• Maximum 250 service per output card (sum of all

8 ports)

• Supports multiplexing and transparent pass

through

• PSI/SI regeneration
• F connector for RF output
• External mute of RF output
• 2 slots wide
• 4 & 16 QAM output models also available

QAM Output

*MC/8QAMOUTMX
