AQD
ATSC/QAM Demodulator 1x 8VSB/QAM 1x AV/2x ASI
Specifications
Connector:
“F” Female
Standards
8VSB:
ATSC Digital Television Standard A/53E
QAM:
ITU-T J.83 (64 and 256 QAM)
8VSB Mode
Tuning Range:
UHF (NTSC Ch. 14-78), VHF (NTSC Ch. 2-13)
Symbol Rate:
10.762 Msymbols/sec
Bandwidth:
6 MHz
QAM Mode
Tuning Range:
CATV (NTSC Ch. 2-135)
Symbol Rate:
5.3606 Msymbols/sec (QAM 256); 5.057
Msymbols/sec (QAM 64) – Auto Detect
Bandwidth:
6 MHz
8VSB Power Level:
-20 to +20 dBmV
QAM Power Level:
-20 to +20 dBmV
Impedance:
75 Ω
Indicators
AQD Module:
Lock (Green LED)
AQD-RCS Module:
Link/Transmit/Receive (3 x Green LEDs)
Local Monitoring:
Front-panel 16-character, 2-line LCD screen
Local Control:
Front-panel Navigational Key-pad
Remote Monitoring/Control:
GUI-based menu via Web browser
(Available if the optional AQD-RCS module is installed)
INPUT
OUTPUT
ALARMS / MONITORING / CONTROL
Dimensions (W x D x H)
AQD/AQD-RCS Module:
1.5 x 11.31 x 5.25 inches (38 x 287 x 133 mm)
AQD-PCM Module:
4.5 x 10.625 x 5.25 inches (114 x 270 x 133 mm)
QTRC Chassis:
19 x 12.0 x 5.25 inches (483 x 305 x 133 mm)
Power:
110 VAC/60 Hz (Fuse:1 A, 250 VDC, SloBlo)
Power Dissipation:
10 W (per AQD module)
Weight
AQD/AQD-RCS Module:
1.5 lbs (0.68 kg)
Fully Loaded Chassis:
24 lbs (10.9 kg)
Operating Temperature:
32 to 122 °F (0 to 50 °C)
Storage Temperature:
-13 to 158 °F (-25 to 70 °C)
Operating Humidity:
0 to 95% RH @ 35 °C max, non-condensation
Storage Humidity:
0 to 95% RH @ 35 °C max, non-condensation
GENERAL
Connector
Video:
“F” Female
Audio:
RCA; Left & Right
NTSC Composite Video
Level:
1 Volt Peak-to-Peak
Flatness:
1.0 dB p/v (30 Hz to 4.2 MHz)
Video to Noise Ratio:
70 dB
Differential Gain:
± 1.0%
Differential Phase:
± 1.0 degree
Format:
480i
Aspect Ratio:
Center Cut, Letterbox, Full, Zoom 1, Zoom 2
Closed Captioning:
EIA-608
L/R Analog Audio
Level:
1.0 to 1.2 Volt Peak-to-Peak (at -20 dBFs input)
Frequency Response:
2.0 dB p/v (30 Hz to 20 KHz)
Modes:
Stereo, Mono, SAP
ASI Output
(AQD PLUS ASI ONLY)
Standard:
DVB-ASI; 50083-9
No. of Streams:
Two identical streams
Data Bit Rate:
270 Mbps
Transport Stream Rate:
160 Mbps (Max)
