Txs 3453, Transcoder, Specifications – Toner Cable TXS3453 MPEG2 Transcoder User Manual

Page 2

Specifications Subject To Change Without Notice

Rev 10-10

©Toner Cable Equipment, Inc.

969 Horsham Road

Horsham, Pennsylvania 19044 USA

Phone: 215-675-2053 Fax: 215-675-7543

[email protected]

ASI I/O
Connectors per chassis:

Up to 8 bidirectional

Connector: BNC
Impedance:

75Ω

Packet format:

Auto detect 188/204 byte

Bitrate:

500 Kbps to 213 Mbps

Syntax:

SPTS or MPTS

IP I/O
Number of Ports:

Up to 4 GbE ports
(2 per platform)

Connector Type:

RJ45 10/100/1000 -
Auto Negotiate

Bitrate:

500 Kbps to 640 Mbps

Addressing:

Unicast and Multicast

IP Encapsulation:

1 to 7 TS/IP

Input Format:

UDP

IGMP compatibility:

Version 1,2 & 3

8-VSB INPUT (OPTIONAL)
Number of ports:

Up to 8

Impedance: 75Ω
Type: F-Type
Frequency:

57-803 MHz (channel 2-69)

Level:

-34 dBmV to +40 dmV

TRANSPORT STREAM PROCESSING
PID Filtering/remapping capabilities
Built-in PSI viewer
Detailed bit rate measurement of incoming services
Ancillary Signal Pass-through for:

• AFD
• DVB Subtitles
• DVB VBI Data (EN301775)
• North American VBI (SCTE 127)
• Closed Captioning (EIA 708)
• Teletex
• SCTE35

TRANSCODER
Multi-format MPEG2/H.264 integrated Decoder/Encoder
Platinum Tier: up to 8 transcodes
Gold Tier:

up to 16 transcodes

Profiles:

H.264 up to HP / L4.1
MPEG2 up to MP@HL

Video Formats:

1080i @ 25 Hz,29.97Hz, 30 Hz
720p @ 50Hz, 59.94 Hz, 60 Hz
480p @ 59.94 Hz
480i @ 29.97 Hz
576 @ 25 Hz

Audio Services:

Up to 4 per transcode

Audio Pass Through:

Dolby Digital (AC-3)
AAC audio ADTS + LOAS
Dolby Digital Plus (EAC-3)
MPEG1/2 audio layers 1 & 2

Video Processing:

Scene detection
Fade detection
De-blocking filter
Skin tone detection

Video bitrate:

100 Kbps to 40 Mbps

Video Output:

CBR or capped VBR

PIP: Secondary

Video

Transcode

Resolution:

96 x 96 up to 240 x 416

Codec:

H.264 or MPEG2

Display Mode:

Letterbox or center-cut

MANAGEMENT
Connector:

RJ-45 10/100 - Auto Negotiate

Protocols:

HTTP and SNMP

User Interface:

Embedded HTML user interface

DIMENSION
Height:

1RU, 1.75” (5cm)

Width:

17.4” (44.2 cm)

Depth:

23” (58 cm)

Power:

100-240 AC 50/60 Hz @ 3 Amps

ENVIRONMENTAL CONDITIONS
Operating Temp:

0° to 45°C

Storage Temp:

-40°C to 65°C

Relative Operating Humidity: <95% (non-condensing)

Specifications

TXS 3453

Transcoder
