Automatic Rate Adjustment Range
720 P: 12-23 Mbs
1080i: 14-25 Mbs
(Rates are calculated based on Component video input
resolution, video complexity and QAM target)
Component Input
Connector:
RCA 75 Ohm
Interface:
RCA YPbPr, RCA unbalanced
L+R audio
Supported Audio:
Dolby Digital 2.0 (AC3) dual stream encoders included
MPEG1 Layer 2 dual stream encoders included
Dolby E, Dolby 5.1 and Dolby Digital 2.0 (AC3)
passthrough
CC Input
Connector:
RCA 75 Ohm
Interface:
Terminated Input for : EIA-608 CC signal reception w/
up convert to EIA-708 for DTV compliance
Wide Screen Signaling (WSS)
Emergency Alert System (EAS) Input
Video:
Connector:
RCA 75 Ohm
Interface:
Terminated NTSC or PAL D1
Composite Input with loop
Audio:
Connector:
Vertical single RCA jack
Interface:
Mono audio channel with loop
EAS Triggering
Interface:
GPI
Web UI
XCP
ASI Output
Connector:
BNC 75 Ohm
Interface:
Asynchronous Serial Interface
(EN 50083-9)
Packet Format:
188 byte packets
Data rate:
up to 210Mbps
Output Format:
MPTS
IP Output
Connector:
RJ45 Electrical Ethernet
Interface:
Internet Protocol
Data Rate:
up to 210Mbps
Syntax:
MPTS
RF Output
Connector:
F-style RF female jack
Frequency:
50 to 862 Mhz
Bandwidth:
6 Mhz Annex B
8 Mhz Annex A
Main Power:
45 dBmV to 56 dBmV in 2 dB
Monitor Power:
-10 dBmV from Main
IF Output
Connector:
F-style RF female/jack
Frequency:
Selectable 44 MHz (USA) and
36.125MHz (Europe)
Signal Specifications
Modulation Schemes Supported:
Annex A
Annex B
MER:
38.0 dB min.
QAM constellations:
Annex A: 64, 256
Annex B: 256
Physical
Operating Temp:
0 to +50 °C/+32 to +122°F
Power Supply (nominal):
100 - 240 VAC
Power Consumption (nominal):
33.6 W (120V @ 280mA)
Weight:
6 lbs
Measurements
(H X W X D)
: 1.73” X 19” X 13.322”
User Interface
Front Panel Controls
Browser-based Web Interface
Specifications
YUV2QAM
Dual Channel High Definition Encoder
with QAM Modulator and RF Up-Conversion
