Yuv2qam, Dual channel high definition encoder, With qam modulator and rf up-conversion

YUV2QAM
Dual Channel High Definition Encoder
with QAM Modulator and RF Up-Conversion
969 Horsham Road
l
Horsham, Pennsylvania 19044 USA
l
Phone: 215-675-2053 Fax: 215-675-7543
l
The YUV2QAM is a dual-channel, high definition
MPEG 2 broadcast distribution encoder with QAM
modulation and RF up-conversion built in. Its pri-
mary application is for use with clear QAM distribu-
tion to ATSC televisions. The YUV2QAM automati-
cally detects video and audio, encodes, multiplexes
and generates program information (PSIP); it then
modulates and up-converts two channels for distrib-
ution via coax. Closed captioning and support for
Emergency Alert (EAS) are standard. Applications
include private cable, hospitality, medical, education
and cable television.
Benefits
• 2-Channel
high definition encoding: The
YUV2QAM automatically detects two channels of
video and audio via RCA input, encodes and multi-
plexes the signal into a multiple program transport
stream with either DVB or ATSC table compliance.
• Automatic video detection: Video rates are auto-
matically adjusted based on RCA video input resolu-
tion, audio passthrough or encode and QAM modula-
tion target.
• QAM modulation and RF up-conversion: For cable
television applications, the unit modulates the signal
using QAM Annex A and B and up-converts two
video and audio services multiplexed on one carrier
frequency for distribution via coax networks.
• ASI and GigE output: For non-RF applications,
theYUV2QAM delivers ASI (75 Ohm source per
EN500083-9) and GigE (MPEG2 or optional RTP
multicast transport egress).
• Program information: The YUV2QAM is compliant
with the ATSC A69 Program and System Information
Protocol (PSIP).
• Closed captioning and EAS: Support for closed
captioning and Emergency Alert (EAS) is standard.
• DVB SI: The YUV2QAM is compliant with ETSI
EN300 468 Service Information specification.
• Flexible configuration & control: Controlling and
configuring the YUV2QAM is easy using the integrat-
ed front panel keypad and LCD and web page for
configuration and monitoring.
Applications
• ATSC Distribution
• DVB Distribution
• Private Cable
- Hospitality
- Medical
- Education
• Cable Television MSOs
