INPUT
Input Level
-39dBm / +10 dBmV, ±3dB
Input Impedance 75 ohm, 18dB return loss
Input Frequency Channel 3 (61.25 MHz Visual Carrier) or
Channel 4 (67.25 MHz Visual Carrier)
Selectable via rear panel switch
Output
Frequency Range
54 to 864 MHz
Standard CATV channels 2 to 135, Normal operation
HRC, IRC Channels 1-135, Selected via internal jumper
Broadcast Channels 2-69, Selected via internal jumper
FCC Offsets Automatic, +12.5 kHz or +25 kHz channel dependant
Output Level +45 dBmV
Output Impedance 75 Ohm, 10 dB return loss
Frequency Stability ± 5kHz
Spurious -60dB @ +45dBmV out
Broadband Noise -77 dBc @ greater than ±12 MHz offset at +45 dBmV output, 4MHz bandwidth
In Channel C/N 57 dB, 4 MHz bandwidth
In Channel Frequency
Response Within 2 dB
Output Level Note The output level of the MPM860AG is intended to be set at or very near
+45dBmV. The front panel gain control adjusts the input level into the
conversion circuitry and not the final output attenuation. For best noise and
spurious performance please adjust the output level to +45dBmV with the
actual input source that will be used with the device. If more than 1 or 2 dB
of variation is needed to properly equalize the system, appropriate attenuators
should be placed on the output of the MPM860AG.
GENERAL
DC Power Input +5 V + or - 5% at 400 mA
+12 V + or - 5% at 200 mA
Operating Temp 0° to +50°C ambient
Size 1" W x 3.5" H x 7.5" D
Weight 12 oz
Specifications
MPM860AG
Channel 3 or 4 Agile Processor
