MPM860AG
Channel 3 or 4 Agile Processor
969 Horsham Road l Horsham, Pennsylvania 19044 USA l Phone: 215-675-2053 Fax: 215-675-7543 l [email protected]
The MPM860AG is a high quality agile channel processor designed to con-
vert an input channel 3 or 4 to any CATV output channel from 2 to 135 or
broadcast channel from 2-69. 1 to 12 processors or other accessories can be
mounted in 2 RU (rack spaces) (3.5"). The MPM860AG joins the legendary
Drake Mini Rack Solution as a device capable of receiving a modulated
channel 3 or 4 from a digital DTA set top box that does not have composite
audio/video outputs. If the output channel is stereo then the MPM860AG will
pass the converted channel as stereo. The MPM860AG may also be used
with other devices having a channel 3 or 4 modulator as well and may serve
as an inexpensive means to provide stereo programs if present in the chan-
nel 3 or 4 output. Like other Drake agile mini rack products a convenient
pushwheel switch is used to select the output channel.
Features
• Convenient Pushwheel Switch for Channel Selection.
• Standard CATV channels 2 - 135 or Broadcast channels 2 - 69 selectable from
front panel.
• IRC & HRC CATV channel formats selectable by internal jumper.
• Channel 3 or 4 input can be double sideband or vestigial sideband.
• SAW filtering for superior adjacent channel performance and removal of undesired
sideband if present at input.
• Stereo ready providing original stream is stereo and passes via channel 3 or 4
• Agility allows for "hot standby" solutions in headends.
• Agility allows for minimal service stock.
• An Economical NTSC channel 3 or 4 channel processor
• +45 dBmV output
• Front panel control of RF output level.
• Complies with FCC Rules Part 76.
• Use up to 12 MPM860AG processors in a two-rack height space powered by a
single PSM121 Power Supply.
• Use up to 4 MPM860AG processors in a one-rack height space by using the
RMM4 Rack and Power Supply.
• Rack mount and high capacity PSM121 Power Supply sold separate
