CU2200 v 3-02
26.10.2012 © Velleman nv 8
Example 2:
PWD:1234,ALMNU1:NUL,3:NUL#%
Password 1234
With example 1, following numbers have been cancelled:
N° 1
12345678, not made
N° 2 36925814712, retained
N° 3 159357456, not made
N° 4 951753654, retained
b. Alarm Setup
• Alarm Input Level & Alert Setup
Command: PWD:XXXX,ALMLEVELR:X,YY,ZZZZBBBB,NNN%
XXXX Password
R
Alarm channel number
X 0 means disabled
1 means closed triggers alarm
2 means open triggers alarm
3 means both closed and open triggered alarm
YY 00 means alarm not reported to control centre
10 means alarm reported to control centre 1
01 means alarm reported to control centre 2
11 means alarm reported to control centre 1 and 2
ZZZZBBBB Selection of the alarm phone dial and alarm SMS
0 means no alarm report
1 means SMS only
2 means phone dial only => (Phone dial not available)
3 means SMS first, then phone dial =>(Phone dial not available)
Z Z Z Z
1
st 2 nd 3 rd 4 th phone number
B B B B
5 th 6 th 7 th 8 th phone number
NNN Relay output control
0 means no relay output control
1 means relay output triggered by alarm
N N N
1 st 2 nd 3 rd relay output
(2 nd and 3 rd relay output not available)
Example 1:
PWD:1234,ALMLEVEL2:1,01,10000000,100%
Password 1234
Alarm channel 2 Once the input is closed, the alarm will be triggered
Control centre 2 will be reported by SMS
Phone number 1
Phone number 2
Phone number 3
Phone number 4-8
Relay output 1
Relay output 2
Relay output 3
SMS message
No report
No report
No report
Triggered “Close” by alarm
No control (not available)
No control (not available)
• SMS Alarm Message Setup
Alarm channel 1 ~ 8
Command: PWD:XXXX,ALMYTEXT:□□□□□□□□□□□□#%
XXXX Password
Y
Alarm channel number (1 ~ 8)
E 0 Close triggered alarm
1 Open triggered alarm
□□□□□□□□ SMS message (max. 130 characters – no space allowed)
Example:
PWD:1234,ALM4T1XT:Door Contact1 Open#%
Password 1234
Alarm channel 4 is triggered by “Open Contact”, SMS message “Door
Contact 1 Open” is sent to the pre-defined phone numbers.
