Page 12
CU2200
v
3-02
26.10.2012
©
Velleman nv
12
X
Alarm report to control centre 2
0 means no report
1 means report
BBBBBBBB
Report status for 8 phone numbers
0 means no report
1 means SMS but no phone dial
2 means phone dial but no SMS
3 means SMS first and then phone dial
CCC
Relay output control
0 means control not triggered by alarm
1 means alarm triggered control
OTY 0000 1
st
relay time lapse
0000 2
nd
relay time lapse
0000 3
rd
relay time lapse
Command: PWD:XXXX,PARAMETER4%
[SMS message received]
ST:XXX;C1:XXXXXXXX,Y;C2:XXXXXXXX,Y;C3:XXXXXXXX,Y;C4:XXXXXXXX,Y;C5:XXXXXXXX,Y;C6:X
XXXXXXX,Y;C7:XXXXXXXX,Y;C8:XXXXXXXX,Y;#
C1 ~ C8
1
st
~ 8
th
Alarm Phone Number
Y
Alarm Report enabled (1) / disabled (0)
• Manual Health Report
Command: PWD:XXXX,STATUS%
[SMS message received]
ST:XXX;T:2005/01/28/13:00;V:XXXX;A1:0000;A2:0000;K1:X;K2:X;K3:X;K4:X;K5:X;K6:X;K7:X;K
8:X;OUT1:Y;OUT2:Y;OUT3:Y;#
12. Technical specifications
Electrical
Power Supply
7 ~ 12VDC
Current
500mA (SMS send/receive), 50mA (standby)
Peak Pulse Current
< 2A
RS232
9 000 bps, 8 stop bits, 1 parity bit
Antenna
GSM900
RF Frequency
925 ~ 960MHz
TX Frequency
880 ~ 912MHz
RF Rating
2W, 12.5% loop loading
GSM1800
RF Frequency
1805 ~ 1880MHz
TX Frequency
1710 ~ 1785MHz
RF Rating
1W, 12.5% loop loading
Dimensions
135 x 105 x 30mm
Total Weight
480g
Loading Resistance
50Ω
Radiation S/N
0 dBi
working temperature
-20°C ~ +50°C
Use this device with original accessories only. Velleman nv cannot be held responsible in the event
of damage or injury resulted from (incorrect) use of this device.
For more info concerning this product and the latest version of this user manual, please visit our
website
www.velleman.eu
.
The information in this manual is subject to change without prior notice.
© COPYRIGHT NOTICE
The copyright to this manual is owned by Velleman nv. All worldwide rights reserved.
No part of this manual or may be copied, reproduced, translated or reduced to any electronic medium or
otherwise without the prior written consent of the copyright holder.
