Features (cont.)
Digital Enable An input providing a connection for a TTL
compatible signal to turn on/off the HV output
Load Range Switch Slide switch to select high or low capacitive
loads (more than 150 pF or less than 150 pF)
Dynamic Adjustment Graduated 1-turn panel potentiometer is used
to optimize the AC response for various load
parameters.
Mechanical
Dimensions
Single Channel
Instrument
Double Channel
Instrument
222.3 mm H x 108 mm W 381 mm D
(8.75” H x 4.25” W x 15” D)
433.8 mm H x 108 mm W 381 mm D
(17” H x 4.25” W x 15” D)
Weight
Single Channel
Instrument
Double Channel
Instrument
4.3 kg (9.4 lb)
8.6 (18.8 lb)
HV Connector SHV High Voltage Connector
BNC Connectors Power Switch, Amplifier Input, Voltage Monitor,
Current Monitor, High Voltage ON/OFF, Digital
Enable
Operating Conditions
Temperature 0°C to 40°C (32°F to 104°F)
Relative Humidity To 85%, noncondensing
Altitude To 2000 meters (6561.68 ft.)
Electrical
Line Voltage Factory Set for one of two ranges:
90 to 127 V AC or 180 to 250 V AC,
either at 48 to 63 Hz
AC Line Receptacle Standard 3-prong with integral fuse holder
Power Consumption 125 VA, maximum
HV Cable 2 m, 66 pF per foot
Supplied Accessories
Operators’ Manual PN: 23166
HV Output Cable PN: 43874
Line Cord
Spare Fuses N5002
Selected per geographic destination
Optional Accessories
19” Rack Mount Kit
Half-Rack Mount Kit
Dual Instrument Rack
Mount Kit Model 603RA
Model 604RA (3 ½” Buckeye)
Model 603RA-2
Copyright ã 2012 TREK, INC. All specifications are subject to change. 1230/DEC
Model 603 Specifications
Performance
Available Output
Voltage Ranges 0 to ±125 V DC or peak AC
0 to -250 V DC or peak AC
0 to +250 V DC or peak AC
Output Current ±40 mA DC
±80 mA peak AC, for less than 1 ms
DC Voltage Gain 50 V/V (a gain of 25 V/V is available)
DC Voltage Gain
Accuracy Better than 0.1% of full scale
DC Offset Voltage Less than ±500 mV
Output Noise* Less than 20 mV rms
Slew Rate
(10% to 90%, typical) Greater than 100 V/µs
Large Signal
Bandwidth
(5% distortion) DC to greater than 150 kHz
Settling Time to 1% Less than 5 µs for a 100 V step
Stability
Drift with Time Less than 100 ppm/hr, noncumulative
Drift with
Temperature
Less than 25 ppm/°C
Amplifier Input
Input Voltage Range 0 to ±10 V DC or peak AC, noninverting
Input Impedance 10 W, nominal
Voltage Monitor
Ratio 1/25th of the high voltage output
DC Accuracy Better than 0.1% of full scale
AC Accuracy Calibrated using a Ross Model VD30-4.1-BD-
KC-ALU high voltage divider
DC Offset Voltage Less than 5 mV
Output Noise Less than 5 mV rms*
Output Impedance 0.1 W
Current Monitor
Ratio 0.1 V/mA
DC Accuracy Greater than 1% of full scale
Offset Voltage Less than 10 mV
Output Noise Less than 10 mV rms*
Output Impedance 0.1 W
Features
Output Voltage
Configuration Factory set for 0 to ±125 VDC or peak AC.
Other ranges available.
*Measured using the true rms feature of the Hewlett Packard 34401A digital multimeter
