31 345D L Hydraulic Excavator specifications
Long Reach Boom Lift Capacities
* Limited to hydraulic capacity rather than tipping load. The above loads are in compliance with hydraulic excavator lift capacity rating standard ISO 10567.
They do not exceed 87% of hydraulic lifting capacity or 75% of tipping capacity. All lifts with heavy lift on.
BOOM – 7.4 m (24'3")
STICK – 4.3 m (14'1") BUCKET – GP-C 2.36 yd 3 – 1820 kg (4,013 lb)
SHOES – 900 mm (36") triple grouser
UNDERCARRIAGE – Long – fixed gauge
COUNTERWEIGHT – 9000 kg (19,842 lb)
Load at Maximum
Reach – Bucket Curled Load Point
Height Load Radius
Over Front Load Radius
Over Side ➤
➤
➤ ➤
4.5 m/15.0 ft 6.0 m/20.0 ft 7.5 m/25.0 ft 9.0 m/30.0 ft 10.5 m/35.0 ft
m m
ft ft
9.0 m kg *6510 *6510 *5660 *5660 7.87 *3850 *3850 10.95
30.0 ft lb *12,850 *12,850 *12,550 *12,550 25.44 *8,500 *8,500 35.60
7.5 m kg *7170 *7170 *5460 *5460 8.84 *3790 *3790 11.79
25.0 ft lb *15,700 15,500 *12,050 *12,050 28.79 *8,350 *8,350 38.49
6.0 m kg *7600 7090 *7140 5120 *5460 4670 9.51 *3830 3680 12.34
20.0 ft lb *16,550 15,200 *14,250 10,900 *12,030 10,400 31.08 *8,450 8,200 40.41
4.5 m kg *9380 *9380 *8260 6810 *7520 4990 *5630 4160 9.93 *3980 3350 12.66
15.0 ft lb *20,300 *20,300 *17,950 14,600 *16,400 10,650 *12,390 9,220 32.54 *8,750 7,400 41.52
3.0 m kg *18 670 *18 670 *13 400 12 810 *10 680 8900 *9040 6470 *7950 4800 *5970 3870 10.14 *4220 3180 12.77
10.0 ft lb *40,050 *40,050 *28,900 27,600 *23,100 19,150 *19,600 13,900 *17,300 10,250 *13,140 8,550 33.25 *9,300 7,000 41.89
1.5 m kg *22 210 18 180 *15 420 11 790 *11 890 8320 *9780 6130 8160 4600 *6520 3750 10.14 *4580 3140 12.67
5.0 ft lb *47,850 39,200 *33,300 25,400 *25,750 17,900 *21,200 13,150 17,500 9,850 *14,340 8,270 33.26 *10,100 6,950 41.57
Ground kg *18 730 17 090 *16 750 11 050 *12 800 7860 10 300 5840 7970 4430 7080 3800 9.93 *5110 3250 12.35
Line lb *43,400 36,750 *36,200 23,800 *27,700 16,900 22,150 12,500 17,100 9,500 15,620 8,380 32.58 *11,250 7,150 40.52
–1.5 m kg *20 680 16 670 *17 250 10 640 *13 230 7550 10 080 5640 7850 4320 7510 4040 9.51 *5870 3520 11.81
–5.0 ft lb *47,400 35,800 *37,350 22,900 *28,650 16,250 21,650 12,100 16,850 9,250 16,570 8,920 31.17 *13,000 7,750 38.70
–3.0 m kg *22 870 16 650 *16 920 10 500 *13 090 7420 9990 5550 7840 4300 8350 4540 8.85 *7050 4050 10.99
–10.0 ft lb *49,550 35,750 *36,600 22,600 *28,300 15,950 21,450 11,900 18,490 10,060 28.94 *15,650 9,000 35.97
–4.5 m kg *20 820 16 890 *15 720 10 580 *12 200 7450 *9480 5600 *8530 5490 7.89
–15.0 ft lb *44,950 36,300 *33,900 22,750 *26,250 16,050 *20,200 12,050 *18,800 12,240 25.71
–6.0 m kg *17 440 17 380 *13 350 10 870 *10 160 7680 *8310 7430 6.53
–20.0 ft lb *37,350 *37,350 *28,500 23,400 *21,450 16,600 *18,230 16,790 21.09
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤ ➤ ➤ ➤ ➤
➤
➤
➤
➤
➤
➤ ➤ ➤
➤
Load at
Maximum Reach
* Limited to hydraulic capacity rather than tipping load. The above loads are in compliance with hydraulic excavator lift capacity rating standard ISO 10567.
They do not exceed 87% of hydraulic lifting capacity or 75% of tipping capacity. All lifts with heavy lift on.
Always refer to the appropriate Operation and Maintenance Manual for specific product information.
BOOM – 7.4 m (24'3")
STICK – 3.9 m (12'10") BUCKET – GP-C 2.36 yd 3 – 1820 kg (4,013 lb)
SHOES – 900 mm (36") triple grouser
UNDERCARRIAGE – Long – fixed gauge
COUNTERWEIGHT – 9000 kg (19,842 lb)
Load at Maximum
Reach – Bucket Curled Load Point
Height Load Radius
Over Front Load Radius
Over Side ➤
➤
➤ ➤
4.5 m/15.0 ft 6.0 m/20.0 ft 7.5 m/25.0 ft 9.0 m/30.0 ft 10.5 m/35.0 ft
m m
ft ft
9.0 m kg *6680 *6680 7.40 *4610 *4610 10.54
30.0 ft lb *14,820 *14,820 23.91 *10,200 *10,200 34.25
7.5 m kg *7760 7260 *6440 6090 8.43 *4530 *4530 11.42
25.0 ft lb *17,050 15,500 *14,220 13,640 27.43 *10,000 *10,000 37.27
6.0 m kg *8150 7120 *6450 5160 9.13 *4580 3980 12.00
20.0 ft lb *17,800 15,250 *14,200 11,470 29.82 *10,100 8,850 39.26
4.5 m kg *10 020 9490 *8790 6870 *7980 5070 *6650 4600 9.56 *4740 3630 12.33
15.0 ft lb *21,700 20,400 *19,100 14,750 *17,400 10,800 *14,630 10,180 31.33 *10,400 8,050 40.40
3.0 m kg *20 080 19 830 *14 240 12 740 *11 290 8930 *9530 6550 *8370 4900 *7060 4280 9.78 *5010 3450 12.43
10.0 ft lb *43,100 42,800 *30,700 27,450 *24,400 19,250 *20,650 14,050 18,150 10,500 *15,530 9,460 32.06 *11,000 7,600 40.79
1.5 m kg *19 350 18 030 *16 130 11 800 *12 430 8400 *10 210 6240 8280 4730 7520 4160 9.78 *5420 3420 12.33
5.0 ft lb *46,100 38,900 *34,800 25,450 *26,900 18,100 *22,150 13,400 17,750 10,100 16,570 9,180 32.08 *11,900 7,550 40.45
Ground kg *17 660 17 180 *17 260 11 160 *13 230 7990 10 440 5980 8120 4580 7670 4230 9.56 *6010 3540 12.00
Line lb *40,900 36,950 *37,300 24,050 *28,600 17,200 22,450 12,850 17,450 9,800 16,910 9,320 31.37 *13,250 7,800 39.37
–1.5 m kg *20 910 16 930 *17 530 10 840 *13 520 7730 10 250 5810 8030 4500 8160 4510 9.13 *6880 3860 11.44
–5.0 ft lb *47,900 36,350 *37,950 23,300 *29,250 16,650 22,050 12,500 17,250 9,650 18,020 9,960 29.92 *15,200 8,550 37.49
–3.0 m kg *22 620 17 000 *16 970 10 760 *13 200 7640 10 200 5760 *8970 5100 8.44 *7450 4470 10.59
–10.0 ft lb *49,000 36,500 *36,700 23,150 *28,500 16,450 21,950 12,400 *19,780 11,300 27.60 *16,400 9,900 34.65
–4.5 m kg *20 240 17 300 *15 490 10 880 *12 070 7720 *8990 6230 7.44
–15.0 ft lb *43,700 37,200 *33,400 23,450 *25,900 16,650 *19,800 13,900 24.21
–6.0 m kg *16 430 *16 430 *12 710 11 230 *9510 8010 *8530 *8530 5.99
–20.0 ft lb *35,100 *35,100 *27,000 24,200 *19,850 17,300 *18,650 *18,650 19.30
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤ ➤ ➤ ➤ ➤
➤
➤
➤
➤
➤
➤ ➤ ➤
➤
Load at
Maximum Reach
