29 345D L Hydraulic Excavator specifications
* Limited to hydraulic capacity rather than tipping load. The above loads are in compliance with hydraulic excavator lift capacity rating standard ISO 10567.
They do not exceed 87% of hydraulic lifting capacity or 75% of tipping capacity. All lifts with heavy lift on.
Always refer to the appropriate Operation and Maintenance Manual for specific product information.
BOOM – 6.9 m (22'8")
STICK – 3.9 m (12'10") BUCKET – GP-C 2.36 yd 3 – 1820 kg (4,013 lb)
SHOES – 900 mm (36") triple grouser
UNDERCARRIAGE – Long – wide variable gauge
COUNTERWEIGHT – 9000 kg (19,842 lb)
Load at Maximum
Reach – Bucket Curled Load Point
Height Load Radius
Over Front Load Radius
Over Side ➤
➤
➤ ➤
4.5 m/15.0 ft 6.0 m/20.0 ft 7.5 m/25.0 ft 9.0 m/30.0 ft 10.5 m/35.0 ft
m m
ft ft
9.0 m kg *6410 *6410 6.96 *4210 *4210 10.07
30.0 ft lb *14,240 *14,240 22.41 *9,350 *9,350 32.7
7.5 m kg *7800 *7800 *6100 *6100 8.00 *4110 *4110 10.97
25.0 ft lb *15,650 *15,650 *13,460 *13,460 26.03 *9,050 *9,050 35.80
6.0 m kg *8410 *8410 *6050 *6050 8.71 *4140 *4140 11.55
20.0 ft lb *18,400 *18,400 *13,330 *13,330 28.46 *9,100 *9,100 37.81
4.5 m kg *10 120 *10 120 *9010 8940 *6860 6680 *6220 *6220 9.14 *4280 *4280 11.88
15.0 ft lb *21,950 *21,950 *19,600 19,200 *12,450 *12,450 *13,680 *13,680 29.95 *9,400 *9,400 38.93
3.0 m kg *19 500 *19 500 *14 140 *14 140 *11 380 *11 380 *9720 8640 *8630 6550 *6590 6310 9.34 *4530 *4530 11.97
10.0 ft lb *41,900 *41,900 *30,500 *30,500 *24,650 *24,650 *21,100 18,550 *16,700 14,000 *14,500 13,920 30.65 *9,950 *9,950 39.27
1.5 m kg *22 970 *22 970 *16 130 15 840 *12 560 11 180 *10 410 8330 8900 6390 *7210 6200 9.32 *4930 *4930 11.83
5.0 ft lb *49,550 *49,550 *34,850 34,100 *27,200 24,050 *22,550 17,900 *18,450 13,700 *15,880 13,670 30.59 *10,850 *10,850 38.84
Ground kg *24 480 23 950 *17 380 15 140 *13 380 10 750 *10 880 8080 8760 6260 *8190 6350 9.08 *5520 5410 11.47
Line lb *52,950 51,400 *37,600 32,600 *28,950 23,150 *23,550 17,350 *16,150 13,450 *18,050 14,010 29.79 *12,150 11,950 37.63
–1.5 m kg *24 390 23 550 *17 730 14 770 *13 670 10 490 *10 950 7920 *9430 6830 8.60 *6400 5920 10.85
–5.0 ft lb *52,850 50,500 *38,400 31,750 *29,600 22,550 *23,650 17,000 *20,800 15,090 28.18 *14,150 13,100 35.56
–3.0 m kg *23 030 *23 030 *17 130 14 670 *13 240 10 400 *10 360 7890 *9610 7800 7.84 *7830 6910 9.92
–10.0 ft lb *49,850 *49,850 *37,050 31,550 *28,550 22,400 *22,200 17,000 *21,200 17,300 25.64 *17,400 15,300 32.43
–4.5 m kg *20 340 *20 340 *15 380 14 820 *11 740 10 520 *9570 *9570 6.74
–15.0 ft lb *43,850 *43,850 *33,050 31,900 *25,050 22,650 *21,070 *21,070 21.9
–6.0 m kg *15 710 *15 710 *11 780 *11 780 *8750 *8750 5.10
–20.0 ft lb *33,350 *33,350 *24,700 *24,700 *19,030 *19,030 16.31
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤ ➤ ➤ ➤ ➤
➤
➤
➤
➤
➤
➤ ➤ ➤
➤
Load at
Maximum Reach
HD Reach Boom Lift Capacities
