28 345D L Hydraulic Excavator specifications
HD Reach Boom Lift Capacities
* Limited to hydraulic capacity rather than tipping load. The above loads are in compliance with hydraulic excavator lift capacity rating standard ISO 10567.
They do not exceed 87% of hydraulic lifting capacity or 75% of tipping capacity. All lifts with heavy lift on.
BOOM – 6.9 m (22'8")
STICK – 3.9 m (12'10") BUCKET – GP-C 2.36 yd 3 – 1820 kg (4,013 lb)
SHOES – 900 mm (36") triple grouser
UNDERCARRIAGE – Long – variable gauge
COUNTERWEIGHT – 9000 kg (19,842 lb)
Load at Maximum
Reach – Bucket Curled Load Point
Height Load Radius
Over Front Load Radius
Over Side ➤
➤
➤ ➤
4.5 m/15.0 ft 6.0 m/20.0 ft 7.5 m/25.0 ft 9.0 m/30.0 ft 10.5 m/35.0 ft
m m
ft ft
9.0 m kg *6410 *6410 6.96 *4210 *4210 10.07
30.0 ft lb *14,240 *14,240 22.41 *9,350 *9,350 32.70
7.5 m kg *7800 *7800 *6090 *6090 8.00 *4110 *4110 10.97
25.0 ft lb *15,650 *15,650 *13,460 *13,460 26.03 *9,050 *9,050 35.80
6.0 m kg *8410 7940 *6050 *6050 8.71 *4140 *4140 11.55
20.0 ft lb *18,400 17,000 *13,330 *13,330 28.46 *9,100 *9,100 37.81
4.5 m kg *10 120 *10 120 *9010 7710 *6860 5710 *6220 5680 9.14 *4280 *4280 11.88
15.0 ft lb *21,950 *21,950 *19,600 16,550 *12,450 12,150 *13,680 12,580 29.95 *9,400 *9,400 38.93
3.0 m kg *19 500 *19 500 *14 140 *14 140 *11 380 10 100 *9720 7420 *8630 5570 *6590 5330 9.34 *4530 4370 11.97
10.0 ft lb *41,900 *41,900 *30,500 *30,500 *24,650 21,750 *21,100 15,900 *16,700 11,900 *14,500 11,770 30.65 *9,950 9,650 39.27
1.5 m kg *22 970 20 980 *16 130 13 520 *12 560 9580 *10 410 7120 8750 5420 *7210 5220 9.32 *4930 4370 11.83
5.0 ft lb *49,550 45,150 *34,850 29,100 *27,200 20,600 *22,550 15,300 *18,450 11,600 *15,880 11,510 30.59 *10,850 9,600 38.84
Ground kg *24 480 19 960 *17 380 12 850 *13 380 9160 *10 880 6870 8610 5290 *8190 5350 9.08 *5520 4550 11.47
Line lb *52,950 42,900 *37,600 27,650 *28,950 19,700 *23,550 14,750 *16,150 11,350 *18,050 11,790 29.79 *12,150 10,050 37.63
–1.5 m kg *24 390 19 580 *17 730 12 480 *13 670 8910 10 890 6710 *9430 5760 8.60 *6400 5000 10.85
–5.0 ft lb *52,850 42,050 *38,400 26,850 *29,600 19,150 23,400 14,450 *20,800 12,710 28.18 *14,150 11,050 35.56
–3.0 m kg *23 030 19 610 *17 130 12 390 *13 240 8820 *10 360 6690 *9610 6590 7.84 *7830 5860 9.92
–10.0 ft lb *49,850 42,100 *37,050 26,650 *28,550 19,000 *22,200 14,400 *21,200 14,620 25.64 *17,400 13,000 32.43
–4.5 m kg *20 340 19 930 *15 380 12 540 *11 740 8940 *9570 8270 6.74
–15.0 ft lb *43,850 42,800 *33,050 27,000 *25,050 19,250 *21,070 18,500 21.90
–6.0 m kg *15 710 *15 710 *11 780 *11 780 *8750 *8750 5.10
–20.0 ft lb *33,350 *33,350 *24,700 *24,700 *19,030 *19,030 16.31
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤ ➤ ➤ ➤ ➤
➤
➤
➤
➤
➤
➤ ➤ ➤
➤
Load at
Maximum Reach
* Limited to hydraulic capacity rather than tipping load. The above loads are in compliance with hydraulic excavator lift capacity rating standard ISO 10567.
They do not exceed 87% of hydraulic lifting capacity or 75% of tipping capacity. All lifts with heavy lift on.
Always refer to the appropriate Operation and Maintenance Manual for specific product information.
BOOM – 6.9 m (22'8")
STICK – 3.35 m (11'0") BUCKET – GP-C 2.36 yd 3 – 1820 kg (4,013 lb)
SHOES – 900 mm (36") triple grouser
UNDERCARRIAGE – Long – variable gauge
COUNTERWEIGHT – 9000 kg (19,842 lb)
Load at Maximum
Reach – Bucket Curled Load Point
Height Load Radius
Over Front Load Radius
Over Side ➤
➤
➤ ➤
3.0 m/10.0 ft 4.5 m/15.0 ft 6.0 m/20.0 ft 7.5 m/25.0 ft 9.0 m/30.0 ft
m m
ft ft
9.0 m kg *4600 *4600 9.56
30.0 ft lb *10,200 *10,200 30.99
7.5 m kg *6860 *6860 *6960 *6960 7.53 *4450 *4450 10.51
25.0 ft lb *15,380 *15,380 24.46 *9,850 *9,850 34.29
6.0 m kg *9680 *9680 *8940 7730 *6850 6750 8.27 *4450 *4450 11.12
20.0 ft lb *21,050 *21,050 *19,550 16,550 *15,090 15,020 27.01 *9,800 *9,800 36.40
4.5 m kg *12 810 *12 810 *10 720 10 400 *9450 7540 *6990 6020 8.73 *4580 *4580 11.46
15.0 ft lb *27,650 *27,650 *23,250 22,350 *20,550 16,150 *15,380 13,340 28.58 *10,050 *10,050 37.57
3.0 m kg *21 000 *21 000 *14 940 14 090 *11 890 9890 *10 080 7270 *7370 5650 8.93 *4820 4600 11.56
10.0 ft lb *45,100 *45,100 *32,250 30,400 *25,750 21,300 *21,900 15,600 *16,210 12,460 29.30 *10,600 10,150 37.92
1.5 m kg *22 450 20 390 *16 680 13 230 *12 920 9410 *10 650 7010 *8030 5540 8.91 *5220 4620 11.42
5.0 ft lb *51,350 43,900 *36,050 28,500 *27,950 20,250 *23,100 15,050 *17,680 12,220 29.24 *11,500 10,150 37.48
Ground kg *7750 *7750 *21 830 19 660 *17 600 12 660 *13 560 9050 *10 970 6800 *9110 5710 8.66 *5810 4850 11.04
Line lb *17,700 *17,700 *50,650 42,250 *38,100 27,250 *29,350 19,450 23,600 14,600 *20,080 12,590 28.40 *12,800 10,700 36.22
–1.5 m kg *14 180 *14 180 *23 860 19 490 *17 600 12 400 *13 610 8850 *10 820 6690 *9760 6210 8.15 *6710 5390 10.39
–5.0 ft lb *32,000 *32,000 *51,750 41,850 *38,100 26,700 *29,400 19,050 *23,300 14,400 *21,530 13,720 26.72 *14,850 11,900 34.04
–3.0 m kg *21 350 *21 350 *22 000 19 660 *16 610 12 400 *12 840 8840 *9730 6740 *9770 7240 7.36 *7900 6440 9.40
–10.0 ft lb *47,300 *47,300 *47,650 42,250 *35,900 26,700 *27,650 19,050 *21,530 16,070 24.05 *17,400 14,300 30.73
–4.5 m kg *23 240 *23 240 *18 730 *18 730 *14 330 12 650 *10 700 9050 *9360 *9360 6.18
–15.0 ft lb *51,850 *51,850 *40,350 *40,350 *30,700 27,250 *22,550 19,550 *20,550 *20,550 20.06
–6.0 m kg *13 150 *13 150 *9530 *9530
–20.0 ft lb
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤ ➤ ➤ ➤ ➤
➤
➤
➤
➤
➤
➤ ➤ ➤
➤
Load at
Maximum Reach
