M318d wheel excavator, Dimensions

background image

Stick Options

Industrial Stick

2.2 m (7'3")

2.5 m (8'3")

2.8 m (9'3")

3.3 m (10'10")

mm

ft/in

mm

ft/in

mm

ft/in

mm

ft/in

1

Shipping Height
VA Boom

3170

10'5"

3170

10'5"

3300

10'10"

3330

10'11"

One-piece Boom

3190

10'6"

3210

10'6"

3330

10'11"

3290

10'10"

2

Shipping Length
VA Boom

8870

29'1"

8850

29'0"

8820

28'11"

8850

29'0"

One-piece Boom

8870

29'1"

8960

29'5"

8950

29'4"

9000

29'6"

3

Support Point
VA Boom

3920

12'10"

3650

12'0"

3510

11'6"

3270

10'9"

One-piece Boom

3810

12'6"

3490

11'5"

3310

10'10"

3080

10'1"

4

Tail Swing Radius
VA Boom and
One-piece Boom

2500

8'2"

2500

8'2"

2500

8'2"

2500

8'2"

5

Counterweight Clearance
VA Boom and
One-piece Boom

1280

4'2"

1280

4'2"

1280

4'2"

1280

4'2"

6

Cab Height
VA Boom and
One-piece Boom

3170

10'5"

3170

10'5"

3170

10'5"

3170

10'5"

Note: All numbers are approximate

Cab height without Falling Object Guards

Dimensions

All dimensions are approximate.

Undercarriage with
dozer only

Undercarriage with 2 sets
of outriggers

Undercarriage with 1 set
of outriggers and dozer

Roading position
with 2.5 m/8'3" stick

5

3

1

4

6

2

2550 mm

8'4"

2540 mm

8'4"

370 mm

1'3"

3820 mm

12'6"

**120 mm

4.7"

** Maximum tire clearance
with outrigger fully down.

500 mm

1'8"

2600 mm

8'6"

1110 mm

3'8"

4250 mm

13'11"

800 mm

2'8"

2600 mm

8'6"

875 mm

2'10"

325 mm

1'1"

4825 mm

15'10"

2600 mm

8'6"

1150 mm

3'9"

1450 mm

4'9"

1110 mm

3'8"

875 mm

2'10"

500 mm

1'8"

4860 mm

15'11"

3350 mm

11'0"

4000 mm

13'1"

M318D Wheel Excavator
