Milton CAT 305.5D CR User Manual
Mini hydraulic excavators
303.5D CR, 304D CR,
305D CR, 305.5D CR
Mini Hydraulic Excavators
303.5D CR
304D CR
305D CR
305.5D CR
Engine
Engine Model
Mitsubishi S3Q2
Mitsubishi S3Q2-T
Mitsubishi S4Q2
Mitsubishi S4Q2-T
Net Power (ISO 9249)
22 kW (30 hp)
29 kW (39 hp)
31 kW (42 hp)
35 kW (47 hp)
Weights
Operating Weight with Canopy
3540 kg (7,800 lb)
3855 kg (8,500 lb)
4995 kg (11,012 lb)
5305 kg (11,696 lb)
Operating Weight with Cab
3700 kg (8,160 lb)
4015 kg (8,852 lb)
5155 kg (11,365 lb)
5465 kg (12,048 lb)
Operating Specifications
Maximum Dig Depth
3180 mm (10'4")
3430 mm (11'3")
3670 mm (12'1")
3870 mm (12'8")
