Hd reach working ranges, Mass working ranges, Heavy duty (hd) reach boom configuration – Milton CAT 345D L User Manual
Page 18: Gp-c 1.8 m, Hd 3.11 m, Gp-c 2.36 yd, Hd 4.07 yd
18
345D L Hydraulic Excavator specifications
HD Reach Working Ranges
Heavy Duty (HD) Reach boom configuration
Mass Working Ranges
Mass (M) boom configuration
345D L Working Ranges – Long Fixed Gauge Undercarriage
Long Reach Boom
HD Reach Boom
Mass Excavation Boom
Stick
R4.3TB
R3.9TB
R3.9TB
R3.35TB
M3.0UB
M2.5UB
(14'1")
(12'10")
(12'10")
(11'0")
(9'10")
(8'2")
Bucket
GP-C 1.8 m
3
GP-C 1.8 m
3
GP-C 1.8 m
3
GP-C 1.8 m
3
HD 3.11 m
3
HD 3.11 m
3
GP-C 2.36 yd
3
GP-C 2.36 yd
3
GP-C 2.36 yd
3
GP-C 2.36 yd
3
HD 4.07 yd
3
HD 4.07 yd
3
1
Maximum Digging Depth
8920 mm
8520 mm
8200 mm
7650 mm
7200 mm
6700 mm
(29'3")
(27'11")
(26'11")
(25'1")
(23'7")
(22'0")
2
Maximum Reach at
12 940 mm
12 580 mm
12 120 mm
11 710 mm
11 160 mm
10 700 mm
Ground Level
(42'5")
(41'3")
(39'9")
(38'5")
(36'7")
(35'1")
3
Maximum Loading Height
7870 mm
7750 mm
7410 mm
7420 mm
6830 mm
6640 mm
(25'10")
(25'5")
(24'4")
(24'4")
(22'5")
(21'9")
4
Minimum Loading Height
2240 mm
2640 mm
2200 mm
2750 mm
2670 mm
3170 mm
(7'4")
(8'8")
(7'3")
(9'0")
(8'10")
(10'5")
5
Maximum Depth Cut for
8790 mm
8380 mm
8070 mm
7500 mm
7050 mm
6530 mm
2440 mm (8') Level Bottom
(28'10")
(27'6")
(26'6")
(24'7")
(23'1")
(21'5")
6
Maximum Vertical Wall
5860 mm
5330 mm
5300 mm
5210 mm
4660 mm
4220 mm
Digging Depth
(19'3")
(17'6")
(17'4")
(17'1")
(15'3")
(13'10")
345D L Working Ranges with Pin Grabber Coupler – Long Fixed Gauge Undercarriage
HD Reach Boom
Stick
R3.35TB (11'0")
Bucket with UB-Family Coupler
GP-C 1.8 m
3
GP-C 2.36 yd
3
1
Maximum Digging Depth
8010 mm (26'4")
2
Maximum Reach at Ground Level
12 070 mm (39'7")
3
Maximum Loading Height
7060 mm (23'1")
4
Minimum Loading Height
2400 mm (7'11")
5
Maximum Depth Cut for 2440 mm (8') Level Bottom
7870 mm (25'10")
6
Maximum Vertical Wall Digging Depth
4010 mm (13'2")
1
2
3
4
5
6
7
8
9
12
13
15
10
9
11
8
7
6
5
4
3
2
1
0
-2
-3
-1
Meters
Feet
35
30
40
45
25
20
15
10
5
-5
0
0
1
2
3
4
5
6
7
8
9
4
5
6
7
8
9
10
11
12
Meters
Feet
0
5
10
15
20
25
30
5
10
15
20
25
30
40
35
14
50
16
1
2
3
4
5
6
7
8
9
12
13
15
10
9
11
8
7
6
5
4
3
2
1
0
-2
-3
-1
Meters
Feet
35
30
40
45
25
20
15
10
5
-5
0
0
1
2
3
4
5
6
7
8
9
4
5
6
7
8
9
10
11
12
Meters
Feet
0
5
10
15
20
25
30
5
10
15
20
25
30
40
35
14
50
16
1
6
5
3
4
2
R4.3TB
R3.9TB
R3.9TB
R3.35TB
1
6
5
3
4
2
M3.0UB
M2.5UB
