26 345D L Hydraulic Excavator specifications
HD Reach Boom Lift Capacities
* Limited to hydraulic capacity rather than tipping load. The above loads are in compliance with hydraulic excavator lift capacity rating standard ISO 10567.
They do not exceed 87% of hydraulic lifting capacity or 75% of tipping capacity. All lifts with heavy lift on.
BOOM – 6.9 m (22'8")
STICK – 3.35 m (11'0") BUCKET – GP-C 2.36 yd 3 – 1820 kg (4,013 lb)
SHOES – 900 mm (36") triple grouser
UNDERCARRIAGE – Long – fixed gauge
COUNTERWEIGHT – 9000 kg (19,842 lb)
Load at Maximum
Reach – Bucket Curled Load Point
Height Load Radius
Over Front Load Radius
Over Side ➤
➤
➤ ➤
3.0 m/10.0 ft 4.5 m/15.0 ft 6.0 m/20.0 ft 7.5 m/25.0 ft 9.0 m/30.0 ft
m m
ft ft
9.0 m kg *7490 *7490 6.28 *4630 *4630 9.44
30.0 ft lb *16,700 *16,700 20.14 *10,250 *10,250 30.60
7.5 m kg *6980 *6980 7.44 *4460 *4460 10.44
25.0 ft lb *15,450 *15,450 24.16 *9,850 *9,850 34.03
6.0 m kg *9600 *9600 *8900 6970 *6840 6120 8.21 *4450 *4450 11.08
20.0 ft lb *20,900 *20,900 *19,500 14,900 *15,090 13,620 26.82 *9,800 *9,800 36.24
4.5 m kg *12 600 *12 600 *10 610 9460 *9390 6790 *6960 5390 8.69 *4560 4270 11.44
15.0 ft lb *27,200 *27,200 *23,000 20,350 *20,450 14,550 *15,330 11,950 28.47 *10,050 9,450 37.50
3.0 m kg *20 620 19 980 *14 740 12 800 *11 780 8950 *10 020 6540 *7320 5010 8.92 *4790 4060 11.56
10.0 ft lb *44,300 43,150 *31,800 27,600 *25,500 19,250 *21,750 14,000 *16,110 11,060 29.27 *10,550 8,950 37.92
1.5 m kg *23 140 18 280 *16 540 11 930 *12 840 8470 *10 610 6270 *7960 4880 8.92 *5170 4050 11.44
5.0 ft lb *51,000 39,400 *35,750 25,700 *27,800 18,200 *23,000 13,450 *17,510 10,770 29.28 *11,400 8,900 37.56
Ground kg *21 560 17 490 *17 550 11 340 *13 520 8100 10 550 6050 8940 5000 8.69 *5740 4240 11.09
Line lb *50,150 37,650 *38,000 24,400 *29,250 17,400 22,650 13,000 19,700 11,030 28.52 *12,650 9,350 36.38
–1.5 m kg *13 540 *13 540 *23 970 17 290 *17 640 11 060 *13 630 7890 10 420 5940 9660 5420 8.22 *6600 4690 10.47
–5.0 ft lb *30,600 *30,600 *52,000 37,150 *38,200 23,800 *29,500 16,950 22,400 12,750 21,330 11,970 26.92 *14,600 10,350 34.29
–3.0 m kg *20 690 *20 690 *22 230 17 430 *16 750 11 040 *12 960 7860 *9910 5970 *9780 6300 7.45 *7950 5600 9.52
–10.0 ft lb *46,750 *46,750 *48,150 37,450 *36,200 23,750 *27,950 16,900 *21,560 13,970 24.35 *17,500 12,400 31.10
–4.5 m kg *22 980 *22 980 *19 130 17 830 *14 620 11 250 *11 010 8040 *9440 8110 6.32
–15.0 ft lb *51,200 *51,200 *41,200 38,350 *31,350 24,250 *23,300 17,350 *20,720 18,160 20.51
–6.0 m kg *13 850 *13 850 *10 210 *10 210
–20.0 ft lb *29,150 *29,150 *20,950 *20,950
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤ ➤ ➤ ➤ ➤
➤
➤
➤
➤
➤
➤ ➤ ➤
➤
Load at
Maximum Reach
BOOM – 6.9 m (22'8")
STICK – 3.35 m (11'0") BUCKET – Bare coupler – 934 kg (2,059 lb)
SHOES – 900 mm (36") triple grouser UNDERCARRIAGE – Long – fixed gauge
COUNTERWEIGHT – 9000 kg (19,842 lb)
* Limited to hydraulic capacity rather than tipping load. The above loads are in compliance with hydraulic excavator lift capacity rating standard ISO 10567.
They do not exceed 87% of hydraulic lifting capacity or 75% of tipping capacity. All lifts with heavy lift on.
Always refer to the appropriate Operation and Maintenance Manual for specific product information.
Load at
Maximum Reach Load Point
Height Load Radius
Over Front Load Radius
Over Side ➤
➤
➤ ➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤
➤
➤ ➤ ➤ ➤ ➤ ➤ ➤
➤
➤
➤
➤
➤
3.0 m/10.0 ft 4.5 m/15.0 ft 6.0 m/20.0 ft 7.5 m/25.0 ft 9.0 m/30.0 ft
m
ft
9.0 m kg
30.0 ft lb *18,260 *18,260 23.67
7.5 m kg *7680 *7680 8.46
25.0 ft lb *17,110 *17,110 27.48
6.0 m kg *10 170 *10 170 *9530 7490 *7550 6870 9.22
20.0 ft lb *22,200 *22,200 *20,900 16,050 *16,760 15,310 30.09
4.5 m kg *13 140 *13 140 *11 180 9910 *10 000 7300 *7640 6130 9.71
15.0 ft lb *28,400 *28,400 *24,300 21,350 *21,800 15,650 *16,960 13,600 31.79
3.0 m kg *21 210 20 430 *15 310 13 240 *12 360 9420 *10 630 7030 *7960 5720 9.98
10.0 ft lb *45,600 44,100 *33,050 28,550 *26,800 20,300 *23,100 15,100 *17,660 12,640 32.71
1.5 m kg *24 040 18 870 *17 160 12 420 *13 440 8950 *11 210 6770 *8520 5550 10.03
5.0 ft lb *52,500 40,650 *37,100 26,800 *29,100 19,300 24,250 14,550 *18,920 12,240 32.90
Ground kg *22 350 18 140 *18 200 11 870 *14 130 8600 11 030 6560 *9410 5600 9.87
Line lb *51,900 39,050 *39,400 25,550 *30,600 18,500 23,750 14,100 20,920 12,360 32.37
–1.5 m kg *14 120 *14 120 *24 730 17 940 *18 300 11 600 *14 250 8400 10 910 6440 10 030 5910 9.49
–5.0 ft lb *31,900 *31,900 *53,650 38,550 *39,650 25,000 *30,850 18,100 23,500 13,900 22,160 13,070 31.08
–3.0 m kg *21 130 *21 130 *22 960 18 040 *17 400 11 570 *13 580 8360 *10 520 6470 *10 590 6600 8.84
–10.0 ft lb *46,900 *46,900 *49,750 38,800 *37,650 24,900 *29,300 18,000 *23,370 14,630 28.90
–4.5 m kg *23 430 *23 430 *19 810 18 390 *15 250 11 760 *11 610 8530 *10 440 7980 7.86
–15.0 ft lb *52,350 *52,350 *42,700 39,550 *32,750 25,350 *24,600 18,450 *23,020 17,820 25.60
–6.0 m kg *14 460 *14 460 *10 790 *10 790 *9510 *9510 6.39
–20.0 ft lb *30,450 *30,450 *22,250 *22,250 *20,750 *20,750 20.56
