924H Wheel Loader Specifications
14
High Lift VersaLink
Operating Specifications with Bucket
Coupler Buckets Pin-On Buckets
Bolt-On Cutting Edge Bolt-On Cutting Edge
Rated bucket capacity (§) m 3 1.8 2.1 2.8 2.8
yd 3 2.4 2.7 3.7 3.7
Struck capacity (§) m 3 1.5 1.7 2.3 2.3
yd 3 2.0 2.2 3.0 3.0
Bucket width mm 2550 2550 2550 2550
ft/in 8'4" 8'4" 8'4" 8'4"
10 Dump clearance at full lift and 45° discharge (§) mm 3335 3267 3129 3220
ft/in 10'11" 10'9" 10'3" 10'7"
14 Reach at full lift and 45° discharge (§) mm 992 1060 1197 1093
ft/in 3'3" 3'6" 3'11" 3'7"
Reach at 45° discharge and 2130 mm (7'0") mm 1947 1985 2054 1995
clearance (§) ft/in
6'5" 6'6" 6'9" 6'7"
Reach with lift arms horizontal mm 2686 2783 2976 2838
and bucket level ft/in 8'10" 9'2" 9'9" 9'4"
20 Digging depth (§) mm 74 82 99 97
in 2.9" 3.2" 3.9" 3.8"
6 Overall length mm 7649 7752 7957 7818
ft/in 25'1" 25'5" 26'1" 25'8"
13 Overall height with bucket at full raise (§) mm 5574 5702 5836 5660
ft/in 18'3" 18'8" 19'2" 18'7"
24 Loader clearance radius with bucket mm 5828 5861 5931 5885
in carry position (§) ft/in
19'1" 19'3" 19'6" 19'4"
Static tipping load straight (§) kg 6789 6621 6410 6718
lb 14,968 14,596 14,131 14,810
Static tipping load full 40° turn (§) kg 5916 5751 5552 5833
lb 13,042 12,679 12,240 12,860
Breakout force (§) kg 9857 9003 7706 8626
lb 21,731 19,848 16,989 19,017
Operating weight kg 11 620 11 754 11 863 11 757
lb 25,618 25,913 26,154 25,920
Static tipping and operating weights shown are for 924H with cab with A/C, optional counterweight, limited slip axles, heavy duty rear brakes,
additional guarding, sound suppression, work tool, 80 kg (176 lb) operator and Michelin 20.5 R25 L3 XHA tires.
(§) Specifications and ratings conform to all applicable standards recommended by the Society of Automotive Engineers (SAE), including
SAE-Standards J732 JUN92 and J742 FEB85 governing ratings.
Other Ground Engaging Tools available, consult your Cat dealer.
