924H Wheel Loader Specifications
10
Transmission
Standard 38.5 km/h 23.9 mph
transmission
max travel speeds
Forward 1 6.7 km/h 4.2 mph
2 12.2 km/h 7.6 mph
3 21.8 km/h 13.5 mph
4 38.5 km/h 23.9 mph
Reverse 1 6.7 km/h 4.2 mph
2 12.2 km/h 7.6 mph
3 21.8 km/h 13.5 mph
Optional low 39 km/h 24.2 mph
speed transmission
max travel speeds
Forward 1 3.7 km/h 2.3 mph
2 7.5 km/h 4.7 mph
3 19.6 km/h 12.2 mph
4 39 km/h 24.2 mph
Reverse 1 4.1 km/h 2.5 mph
2 8.1 km/h 5 mph
3 21.2 km/h 13.2 mph
Tires
Size 20.5 R25 Radial (L-3)
Tread width 1880 mm 6 ft 3 in
• Choice of:
• 17.5-25, 12PR (L-2)
• 17.5-25, 12PR (L-3)
• 17.5 R25, radial (L-2)
• 17.5 R25, radial (L-3)
• 20.5-25, 12PR (L-2)
• 20.5-25, 12PR (L-3)
• 20.5 R25, radial (L-2/L-3)
• 550/65 R25, radial (L-3)
• Other tire choices are available, contact your
Cat ® Dealer for details.
• In certain applications, the loader’s productive
capabilities may exceed the tire’s tonnes-
km/h (ton-mph) capabilities. Caterpillar
recommends that you consult a tire supplier
to evaluate all conditions before selecting
a tire model.
Cab
ROPS SAE J1040 MAY94,
ISO 3471-1994
FOPS SAE J/ISO 3449 APR98
Level II, ISO 3449 1992
Level II
• Caterpillar cab and Rollover Protective
Structure (ROPS) are standard in North
America and Europe.
• When properly installed and maintained, the
cab offered by Caterpillar, when tested with
doors and windows closed as per work cycle
procedures specified in ANSI/SAE J1166
May 90, results in operator sound exposure
Leq (equivalent sound pressure level) of
74 dB(A).
Operating Specifications
Static tipping load 7276 kg 16,041 lb
(full turn)
Reach – full lift/
992 mm 3 ft 3 in
45 degree
dump angle
Dump clearance –
2828 mm 9 ft 3 in
full lift/45 degree
dump angle
Articulation angle
40° 40°
