E M C P 3 . 2
G E N E R A T O R S E T C O N T R O L L E R
LEHE4942-02
3
WARNING/SHUTDOWN INDICATION
● Overcrank
● Low Coolant Temperature Warning
● High Coolant Temperature Warning/Shutdown
● Low Oil Pressure Warning/Shutdown
● Overspeed
● Control Switch Not In Auto
● High/Low Battery Voltage
● Emergency Stop Activated
Notes:
● Warning condition activates common alarm
output signal and common flashing yellow
indicating lamp.
● Shutdown condition activates common
shutdown output signal and common flashing
red indicating lamp.
● Warning/Shutdown conditions result in text
message in EMCP 3 display event log.
DIGITAL INPUTS (8 TOTAL)
● Emergency Stop
● Remote Start
● 6 Programmable
Digital inputs can be programmed for various
alarm, shutdown, and status conditions including:
● Low Fuel Level
● High Fuel Level
● Fuel Leak Detected
● High Exhaust Temperature
● Air Damper Closed
● Circuit Breaker Open/Closed
● Low Engine Oil Level
● Low Coolant Level
● Low Starting Air Pressure
● Low/High Ambient Air Temperature
● Spare Fault #1-6.
Inputs can be programmed for either high or low
activation using programmable Normally Open
or Normally Closed contacts.
Note: The number of programmable Digital Inputs
may vary based on specific package configuration.
Refer to Engine Installation Guide for specific
engine application.
PROTECTIVE RELAYING
● Generator Over/Under Voltage
● Generator Over/Under Frequency
● Generator Overcurrent
RELAY OUTPUTS (8 TOTAL)
● Starter Motor
● Fuel Control
● 6 Programmable
Relay outputs can be programmed for various
operating conditions including: Air shut-off, or
pre-lube, Common Alarm, Common Shutdown,
Common Warning, Engine Running, Crank Alert,
& Idle/Rated.
Relays are rated for 2A @ 30 VDC and consist
of 6 Form A (Normally Open) contacts. Two of
the programmable outputs are Form C
(Normally Open & Normally Closed) contacts.
Note: These are only rated for DC.
Note: The number of programmable Relay Outputs
may vary based on specific package configuration.
Refer to Engine Installation Guide for specific
engine application.
DISCRETE OUTPUTS
● 1 Programmable
Discrete output can be programmed for various
operating conditions including: Air shut-off,
pre-lube, Common Alarm, Common Shutdown,
Common Warning, Engine Running, Crank Alert,
& Idle/Rated.
Discrete output can sink up to 300mA
and is suitable for driving relay coils or
incandescent lamps.
SENSOR INPUTS
● Engine Speed (Magnetic Pick-up)
● Engine Oil Pressure (0-2 k
Ω resistive sender,
1 or 2-wire) – MUI Engines only
● Engine Coolant Temperature (0-2 k
Ω resistive
sender, 1 or 2-wire) – MUI Engines only
● Configurable Input (0-2 k Ω resistive sender)
(for engine oil temperature, etc)
STANDARD FEATURES (CONT’D)
AVAILABLE LOCAL DISPLAY LANGUAGES
• Arabic • Italian
• Czech • Latvian
• Danish • Lithuanian
• Dutch • Norwegian
• Estonian • Polish
• Finnish • Portuguese
• French • Russian
• German • Spanish
• Greek • Slovak
• Hungarian • Slovene
• Icelandic • Swedish
• Turkish
Note: Displays contain 2 languages
(English and Local)
