FEATURES DESCRIPTION
A T T A C H M E N T S
C18 SUB-BASE
FUEL TANK BASE
Diesel Generator Set
506 – 700 kVA 50 Hz
492 – 600 kW 60 Hz
● UL 142
● Designed and built to comply with
NFPA 30, 37, 110
● Dual wall
● Fuel level gauge
● Alarms and shutoff for low fuel level
● Fill and vent facility with cap
● Linear vibration isolators between base and
engine-generator
● Tank design provides capacity for thermal
expansion of fuel
● Fuel supply dip tube is positioned so as not to
pick up fuel sediment
● Fuel return and supply dip tube is separated by
an internal baffle to prevent immediate re-supply
of heated return fuel
● Pressure washed with an iron phosphate solution
● Interior coated with a solvent-based film rust
preventative
● Heavy 7 gauge steel construction
● Both tanks are leak tested at 3 psi
● Compatible with enclosures
● Basin drain
● Gloss black polyester alkyd enamel exterior
paint over urethane based primer
● The sub-base fuel tank mounts below the
generator set skid base.
● The capacity of the outer tank is a minimum of
10% larger (110% of inner tank) to contain the
fuel if the inner tank leaks or ruptures.
● Both tanks are separately vented.
● Mechanical direct read fuel gauge
● Fuel fill – 4" opening lockable flip top
● Compatible with 3406, 3456, C9, C15 and C18
generator sets leak detection switch
● Leak detection switch
OPTIONS
● Manual fuel transfer pump
● Auto fuel transfer system
– Remote above ground supply
– Below floor storage
– Gravity supply
● Low fuel level switch
LEHE5413-00
