40EPF.. Soft Recovery Series
Vishay High Power Products Fast Soft Recovery
Rectifier Diode, 40 A
ORDERING INFORMATION TABLE
LINKS TO RELATED DOCUMENTS
Dimensions http://www.vishay.com/doc?95223
Part marking information http://www.vishay.com/doc?95226
1 - Current rating (40 = 40 A)
2 - Circuit configuration:
E = Single diode
3 - Package:
P = TO-247AC modified
4 - Type of silicon:
F = Fast recovery
5 - Voltage code x 100 = V
RRM
6 - None = Standard production
PbF = Lead (Pb)-free
10 = 1000 V
12 = 1200 V
Device code
5 1 3 2 4 6
40 E P F 12 -
