Document Number: 94509

For technical questions, contact: [email protected]

www.vishay.com

Revision: 21-Jul-08

1

Ultrafast Rectifier,

2 x 35 A FRED Pt

TM

70CRU02PbF

Vishay High Power Products

FEATURES

• Two common-cathode diodes
• Ultrafast reverse recovery
• Ultrafast reverse recovery current shape
• Low forward voltage drop
• Low leakage current
• Optimized for power conversion: welding and industrial

SMPS applications

• Up to 175 °C operating junction temperature
• Lead (Pb)-free (“PbF” suffix)
• Designed and qualified for industrial level

DESCRIPTION

The 70CRU02 integrates two state of the art Vishay HPP
ultrafast recovery rectifiers in the common-cathode
configuration. The planar structure of the diodes, and the
platinum doping life-time control, provide a ultrasoft recovery
current shape, together with the best overall performance,
ruggedness and reliability characteristics. These devices are
thus intended for high frequency applications in which the
switching energy is designed not to be predominant portion
of the total energy, such as in the output rectification stage
of welding machines, SMPS, dc-to-dc converters. Their
extremely optimized stored charge and low recovery current
reduce both over-dissipation in the switching elements (and
snubbers) and EMI/RFI.

PRODUCT SUMMARY

t

rr

28 ns

I

F(AV)

at T

C

= 145 °C

2 x 35 A

V

R

200 V

Base

common

cathode

Anode

Common

cathode

1

2

1

2

2

Anode

3

TO-218

Available

RoHS*

COMPLIANT

ABSOLUTE MAXIMUM RATINGS

PARAMETER

SYMBOL

TEST CONDITIONS

MAX.

UNITS

Continuous forward current per diode

I

F(AV)

T

C

= 145 °C

35

A

Cathode to anode voltage

V

R

200

V

Single pulse forward current per diode

I

FSM

T

C

= 25 °C

300

A

Maximum power dissipation per module

P

D

T

C

= 100 °C

67

W

Operating junction and storage temperatures

T

J

, T

Stg

- 55 to 175

°C

ELECTRICAL SPECIFICATIONS PER DIODE (T

J

= 25 °C unless otherwise specified)

PARAMETER SYMBOL

TEST

CONDITIONS

MIN.

TYP.

MAX.

UNITS

Breakdown voltage,
blocking voltage

V

BR

,

V

R

I

R

= 60 µA

200

-

-

V

Forward voltage

V

F

I

F

= 35 A

-

0.95

1.09

I

F

= 35 A, T

J

= 125 °C

-

0.9

1.0

I

F

= 35 A, T

J

= 175 °C

-

0.85

0.9

Reverse leakage current

I

R

V

R

= V

R

rated

-

-

60

µA

T

J

= 150 °C, V

R

= V

R

rated

-

-

2

mA

Junction capacitance

C

T

V

R

= 200 V

-

50

-

pF

Series inductance

L

S

Measured from A-lead to K-lead 5 mm
from package body

-

10

-

nH

* Pb containing terminations are not RoHS compliant, exemptions may apply
