Ultralow V
F
Hyperfast Rectifier for
Discontinuous Mode PFC, 8 A FRED Pt
TM
8ETL06PbF/8ETL06FPPbF
Vishay High Power Products
FEATURES
• Benchmark ultralow forward voltage drop
• Hyperfast recovery time
• Low leakage current
• 175 °C operating junction temperature
• Fully isolated package (V
INS
= 2500 V
RMS
)
• UL E78996 approved
• Lead (Pb)-free
• Designed and qualified for industrial level
DESCRIPTION
State of the art, ultralow V
F
, soft-switching hyperfast rectifiers
optimized for Discontinuous (Critical) Mode (DCM) Power
Factor Correction (PFC).
The minimized conduction loss, optimized stored charge and
low recovery current minimize the switching losses and
reduce over dissipation in the switching element and
snubbers.
The device is also intended for use as a freewheeling diode
in power supplies and other power switching applications.
APPLICATIONS
AC-DC SMPS 70 W to 400 W
e.g. laptop and printer AC adaptors, desktop PC, TV and
monitor, games units and DVD AC-DC power supplies.
PRODUCT SUMMARY
V
F
(typical)
0.96 V
I
F(AV)
8 A
V
R
600 V
Anode
1
3
Cathode
Base
cathode
2
Anode
1
3
Cathode
TO-220AC
TO-220 FULL-PAK
8ETL06PbF
8ETL06FPPbF
Available
Pb-free
RoHS*
COMPLIANT
ABSOLUTE MAXIMUM RATINGS
PARAMETER SYMBOL
TEST
CONDITIONS
VALUES
UNITS
Repetitive peak reverse voltage
V
RRM
600
V
Average rectified forward current
I
F(AV)
T
C
= 160 °C
8
A
FULL-PAK
T
C
= 142 °C
Non-repetitive peak surge current
I
FSM
T
J
= 25 °C
175
Repetitive peak forward current
I
FM
16
Operating junction and storage temperatures
T
J
, T
Stg
- 65 to 175
°C
ELECTRICAL SPECIFICATIONS (T
J
= 25 °C unless otherwise specified)
PARAMETER SYMBOL
TEST
CONDITIONS
MIN.
TYP.
MAX.
UNITS
Breakdown voltage,
blocking voltage
V
BR
,
V
R
I
R
= 100 µA
600
-
-
V
Forward voltage
V
F
I
F
= 8 A
-
0.96
1.05
I
F
= 8 A, T
J
= 150 °C
-
0.81
0.86
Reverse leakage current
I
R
V
R
= V
R
rated
-
0.05
5
µA
T
J
= 150 °C, V
R
= V
R
rated
-
20
100
Junction capacitance
C
T
V
R
= 600 V
-
17
-
pF
Series inductance
L
S
Measured lead to lead 5 mm from package body
-
8.0
-
nH
* Pb containing terminations are not RoHS compliant, exemptions may apply
