Ultrafast Soft Recovery Diode,
60 A FRED Pt
TM
60EPU06PbF/60APU06PbF
Vishay High Power Products
FEATURES
• Ultrafast recovery
• 175 °C operating junction temperature
• Lead (Pb)-free (“PbF” suffix)
• Designed and qualified for industrial level
BENEFITS
• Reduced RFI and EMI
• Higher frequency operation
• Reduced snubbing
• Reduced parts count
DESCRIPTION/APPLICATIONS
These diodes are optimized to reduce losses and EMI/RFI
in high frequency power conditioning systems.
The softness of the recovery eliminates the need for a
snubber in most applications. These devices are ideally
suited for HF welding, power converters and other
applications where switching losses are not significant
portion of the total losses.
PRODUCT SUMMARY
t
rr
(typical)
34 ns
I
F(AV)
60 A
V
R
600 V
Cathode
to base
2
1
3
Cathode
Anode
60EPU06PbF
TO-247AC modified
Cathode
to base
2
Anode
Anode
TO-247AC
60APU06PbF
1
3
Available
Pb-free
RoHS*
COMPLIANT
ABSOLUTE MAXIMUM RATINGS
PARAMETER SYMBOL
TEST
CONDITIONS
MAX.
UNITS
Cathode to anode voltage
V
R
600
V
Continuous forward current
I
F(AV)
T
C
= 116 °C
60
A
Single pulse forward current
I
FSM
T
C
= 25 °C
600
Maximum repetitive forward current
I
FRM
Square wave, 20 kHz
120
Operating junction and storage temperatures
T
J
, T
Stg
- 55 to 175
°C
ELECTRICAL SPECIFICATIONS (T
J
= 25 °C unless otherwise specified)
PARAMETER SYMBOL
TEST
CONDITIONS MIN.
TYP.
MAX.
UNITS
Breakdown voltage,
blocking voltage
V
BR
,
V
R
I
R
= 100 µA
600
-
-
V
Forward voltage
V
F
I
F
= 60 A
-
1.35
1.68
I
F
= 60 A, T
J
= 125 °C
-
1.20
1.42
I
F
= 60 A, T
J
= 175 °C
-
1.11
1.30
Reverse leakage current
I
R
V
R
= V
R
rated
-
-
50
µA
T
J
= 150 °C, V
R
= V
R
rated
-
-
500
Junction capacitance
C
T
V
R
= 600 V
-
39
-
pF
* Pb containing terminations are not RoHS compliant, exemptions may apply
