Hyperfast Rectifier,
30 A FRED Pt
TM
30EPH06PbF
Vishay High Power Products
FEATURES
• Hyperfast recovery time
• Low forward voltage drop
• Low leakage current
• 175 °C operating junction temperature
• Single diode device
• Lead (Pb)-free (“PbF” suffix)
• Designed and qualified for industrial level
DESCRIPTION/APPLICATIONS
State of the art hyperfast recovery rectifiers designed with
optimized performance of forward voltage drop, hyperfast
recovery time and soft recovery.
The planar structure and the platinum doped life time
control guarantee the best overall performance, ruggedness
and reliability characteristics.
These devices are intended for use in PFC boost stage in
the AC-DC section of SMPS, inverters or as freewheeling
diodes.
Their extremely optimized stored charge and low recovery
current minimize the switching losses and reduce over
dissipation in the switching element and snubbers.
PRODUCT SUMMARY
t
rr
(typical)
28 ns
I
F(AV)
30 A
V
R
600 V
Base
common
cathode
2
1
3
Cathode
Anode
TO-247AC modified
Available
Pb-free
RoHS*
COMPLIANT
ABSOLUTE MAXIMUM RATINGS
PARAMETER SYMBOL
TEST
CONDITIONS
VALUES
UNITS
Peak repetitive reverse voltage
V
RRM
600
V
Average rectified forward current
I
F(AV)
T
C
= 116 °C
30
A
Non-repetitive peak surge current
I
FSM
T
J
= 25 °C
300
Operating junction and storage temperatures
T
J
, T
Stg
- 65 to 175
°C
ELECTRICAL SPECIFICATIONS (T
J
= 25 °C unless otherwise specified)
PARAMETER SYMBOL
TEST
CONDITIONS
MIN.
TYP.
MAX.
UNITS
Breakdown voltage,
blocking voltage
V
BR
,
V
R
I
R
= 100 µA
600
-
-
V
Forward voltage
V
F
I
F
= 30 A
-
2.0
2.6
I
F
= 30 A, T
J
= 150 °C
-
1.34
1.75
Reverse leakage current
I
R
V
R
= V
R
rated
-
0.3
50
µA
T
J
= 150 °C, V
R
= V
R
rated
-
60
500
Junction capacitance
C
T
V
R
= 600 V
-
33
-
pF
Series inductance
L
S
Measured lead to lead 5 mm from package body
-
3.5
-
nH
* Pb containing terminations are not RoHS compliant, exemptions may apply
