40EPF.. Soft Recovery Series
Vishay High Power Products Fast Soft Recovery
Rectifier Diode, 40 A
ELECTRICAL SPECIFICATIONS
PARAMETER SYMBOL TEST CONDITIONS VALUES UNITS
Maximum forward voltage drop V
FM
40 A, T
J
= 25 °C 1.4 V
Forward slope resistance r
t
T
J
= 125 °C
6.82 m Ω
Threshold voltage V
F(TO)
0.94 V
Maximum reverse leakage current I
RM
T
J
= 25 °C
V
R
= Rated V
RRM
0.1
mA
T
J
= 150 °C 10
RECOVERY CHARACTERISTICS
PARAMETER SYMBOL TEST CONDITIONS VALUES UNITS
Reverse recovery time t
rr I
F
at 10 Apk
25 A/µs
25 °C
450 ns
Reverse recovery current I
rr
6 A
Reverse recovery charge Q
rr
1.8 µC
Snap factor S 0.5
I
FM
t
rr
dir
dt
I
RM(REC)
Q
rr
t
THERMAL - MECHANICAL SPECIFICATIONS
PARAMETER SYMBOL TEST CONDITIONS VALUES UNITS
Maximum junction and storage
temperature range
T
J
, T
Stg
- 40 to 150 °C
Maximum thermal resistance,
junction to case
R
thJC
DC operation 0.6
°C/W
Maximum thermal resistance,
junction to ambient
R
thJA
40
Typical thermal resistance,
case to heatsink
R
thCS
Mounting surface, smooth and greased 0.2
Approximate weight
6 g
0.21 oz.
Mounting torque
minimum 6 (5) kgf · cm
(Ibf · in) maximum 12 (10)
Marking device Case style TO-247AC modified (JEDEC)
40EPF10
40EPF12
