Document Number: 93469
For technical questions, contact:
www.vishay.com
Revision: 21-Dec-10
5
VSMD400AW60, VSMD400CW60
Standard Recovery Diodes, 400 A
Vishay Semiconductors
Preliminary
ORDERING INFORMATION TABLE
CIRCUIT CONFIGURATION
CIRCUIT DESCRIPTION
CIRCUIT CONFIGURATION CODE
CIRCUIT DRAWING
Common anode
A
Common cathode
C
1
-
Vishay Semiconductors product
2
-
MD = Standard recovery diode
3
-
Current rating (400 = 400 A)
-
Circuit configuration:
4
5
6
-
Type of device:
-
Voltage rating (60 = 600 V)
W = TO-244 not isolated
Device code
5
1
3
2
4
6
VS
MD
400
C
W
60
C = Common cathode
A = Common anode
Base common cathode
Lug
terminal
cathode 2
Lug
terminal
cathode 1
Base common cathode
Lug
terminal
anode 2
Lug
terminal
anode 1
