Standard Recovery Diodes, 400 A
VSMD400AW60, VSMD400CW60
Vishay Semiconductors
Preliminary
FEATURES
• Standard rectifier
• Popular series for rough service
• Cathode and anode to base available
• Compliant to RoHS Directive 2002/95/EC
• Designed and qualified for industrial level
TYPICAL APPLICATIONS
• Welders
• Power supplies
• Motor controls
• Battery chargers
• General industrial current rectification
ELECTRICAL SPECIFICATIONS
PRODUCT SUMMARY
I
F(AV)
per module
400 A
Type
Modules - Diode, High Voltage
TO-244
MAJOR RATINGS AND CHARACTERISTICS
SYMBOL
CHARACTERISTICS
VALUES
UNITS
I
F(AV)
133 °C
400
A
I
F(RMS)
628
I
FSM
50 Hz
2500
60 Hz
2620
I
2
t
50 Hz
31
kA
2
s
60 Hz
28
I
2
√t
312
kA
2
√s
V
RRM
600
V
T
J
- 40 to 175
°C
T
Stg
VOLTAGE RATINGS
TYPE NUMBER
VOLTAGE
CODE
V
RRM
, MAXIMUM REPETITIVE
PEAK REVERSE VOLTAGE
V
V
RSM
, MAXIMUM NON-REPETITIVE
PEAK REVERSE VOLTAGE
V
I
RRM
MAXIMUM
AT T
J
= 175 °C
mA
VSMD400.W60
60
600
700
12
